Standard Features

• Smart touch display with single-button operation
• Top & bottom S-shaped wash fields
• Variopower washing pressure adjustment
• Integrated chemical pumps
• Rinse booster pump
• Drain pump
• EnergyLight waste water heat recovery system
• Quadruple filtration system
• Clouding sensor
• Connected wash technology
• Automatic start-up and shut-down timer

Product Benefits

First-Class Wash Results

Removes even the toughest dirt with certified cleanliness and hygiene. The powerful wash system and advanced filtration ensure excellent results.

Absolute Reliability

Built with innovative technology and high-quality materials, the PT Series is designed for long-lasting durability and minimal errors.

Highly Economical

Uses less water, energy, and chemicals, making it a cost-effective choice for commercial kitchens.

Simple to Use

Intuitive operation, ergonomic design, and practical functionality make the PT Series user-friendly for kitchen staff.

Technical Information

• Clear entry height: 440 mm
• Dimensions (WxDxH): 735 x 750 x 1705-2300 mm
• Rack Dimensions: 500 x 500 mm, 500 x 600 mm
• Rinse Water Consumption: 2.2L per cycle

Water Connection

• Connection Point: 3/4 inch (19mm)
• Flow Pressure: Min. 1.0 bar
• Flow Rate: 4 L/min
• Max. Inlet Temperature: 60°C
• Wastewater Connection: 23.6 mm

Electrical Specifications

• 3 Phase (Standard): 415V 3P 50Hz - 20amp (TCL 9.7Kw)
• 3 Phase (Optional): 415V 3P 50Hz - 25amp (TCL 11.5Kw), 415V 3P 50Hz - 32amp (TCL 15.7Kw)

General Data

• Cycle Times: 50/80/110 Seconds (Adjustable)
• Noise Emission: 62dB(A)
• Tank Capacity: 35L
• Weight (Net/Gross): 172/202 kg

Standard Inclusions

• 1x 1m Flexible Waste Hose
• 1x 1m Flexible Water Connection Hose
• 1x 3-phase Lead
• 2x 500 x 500 Racks (1x Flat, 1x Plate)
