Overview

AG Equipment GNX3100BT Three Door Commercial Worktop / Under Bench Freezer 700mm Depth

The AG Equipment GNX3100BT is a three door commercial worktop and under bench freezer built for the demands of busy kitchens, cafes, bars and food service operations. Constructed from stainless steel, it combines generous 417L storage capacity with a full-width bench top surface, making it a highly practical dual-purpose unit. It features a CUBIGEL compressor, Carel iJF digital controller with NFC and Bluetooth connectivity, fan-forced ventilated cooling, and an automated defrosting system, all operating on R290 refrigerant for energy-efficient, environmentally responsible performance.

The redesigned X-series positions dual fans at the front and side of the unit, freeing the rear ventilation space entirely so the freezer can be installed flush against a back wall. Only 150mm of clearance at the side and front is required. Each of the three self-closing doors provides two adjustable wire shelves capable of holding a 1/1 GN tray or rack per shelf, with centre shelf connectors preventing items from falling through between sections. Pre-installed castor wheels allow easy repositioning, and the unit is backed by a 24-month parts and labour warranty from AG Equipment.

Key Benefits

• Dual-purpose design provides both secure frozen storage and a usable stainless steel bench top surface, maximising floor space efficiency in tight kitchen layouts.
• Flush-to-wall installation capability, requiring only 150mm side and front clearance, frees up valuable floor space compared with rear-vented units.
• R290 natural refrigerant is ozone-safe, non-toxic, and can reduce overall energy costs by up to 28% compared with conventional refrigerants.
• Carel iJF controller with Bluetooth and NFC enables remote temperature monitoring and adjustment via the CONTROLLA mobile app on Android and Apple devices, reducing manual checks.
• Automated defrosting system minimises staff intervention and helps maintain consistent frozen temperatures throughout service.
• Two adjustable wire shelves per door accommodate full 1/1 GN trays or racks, keeping frozen stock organised and immediately accessible during service.
• Centre shelf connectors bridge the gap between shelf sections, preventing smaller items from falling through and reducing product loss or retrieval delays.
• Self-closing doors with recessed handles help maintain stable cabinet temperatures even during busy service periods when doors may be left momentarily unattended.
• Pre-installed castor wheels make the unit straightforward to reposition for cleaning or kitchen reconfiguration without additional equipment.

Key Features

• Stainless steel body construction throughout
• Three self-closing doors with recessed handles
• 417L total storage capacity
• Two adjustable wire shelves per door, each accommodating a 1/1 GN tray or rack
• Centre shelf connectors between shelf sections to prevent items falling through
• CUBIGEL compressor
• Carel iJF digital controller with NFC and Bluetooth connectivity
• Frameless flat-design Carel iJF controller with fault alarm warnings and data logging
• CONTROLLA mobile app compatibility for electronic and remote temperature control (Android and Apple)
• Temperature set range: -16°C to -22°C
• Fan-forced ventilated cooling with dual fans positioned at the front and side of the unit
• Automated defrosting system
• R290 natural refrigerant (non-toxic, ozone-safe, low global warming potential)
• Flush-to-wall installation capability; 150mm clearance required at side and front only
• Pre-installed castor wheels
• Rated ambient operating conditions: 43°C / 65% relative humidity
• 700mm depth
• 24-month parts and labour warranty
• Part of the AG Equipment X-series commercial refrigeration range

Specifications

• Weight (kg): 742.5
