Overview

Blue Seal E516B-B Evolution Series 900mm Electric Cooktop Bench Model

The Blue Seal E516B-B is a 900mm bench-mount electric cooktop from the Evolution Series, combining two 2.4kW radiant elements with a 600mm smooth mild steel griddle plate powered by dual 3.4kW elements. This multi-zone configuration lets kitchen teams boil, sauté, and grill at the same time, improving throughput during busy service periods in cafés, restaurants, and catering operations.

Built in New Zealand from heavy-duty 304 stainless steel, the E516B-B is engineered to withstand the rigours of daily commercial use. The griddle is positioned on the right-hand side as standard, energy regulator controls allow precise heat adjustment across the full spectrum, and the bench-mount design with four stainless steel legs and adjustable feet integrates cleanly into existing modular Evolution Series lineups.

Key Benefits

• Multi-zone cooking surface lets chefs boil, sauté, and flat-plate grill simultaneously, reducing bottlenecks during peak service.
• Energy regulator controls on the radiant elements enable fine heat adjustment from a gentle simmer through to high-heat searing.
• 600mm smooth mild steel griddle delivers even heat distribution across a large flat cooking surface, ideal for breakfast menus, proteins, and vegetables.
• Griddle positioned on the right-hand side as standard suits conventional kitchen workflow and plating direction.
• Heavy-duty reinforced control knobs with clear, non-fade markings and strengthened shaft sleeves reduce the need for frequent knob replacement, lowering maintenance costs.
• Adjustable feet and two additional rollers allow precise levelling and straightforward repositioning during kitchen reconfiguration.
• Four stainless steel bench legs and a 165mm splashback keep the unit hygienic and protect surrounding surfaces from heat and grease splash.
• Optional solid hot plate elements provide cooking surface flexibility to suit changing menu requirements.
• Modular Evolution Series compatibility allows the unit to be paired with other Blue Seal 900mm modules for a coordinated, space-efficient cooking suite.

Key Features

• 900mm wide bench-mount electric cooktop, part of the Blue Seal Evolution Series
• 2 x 2.4kW radiant elements on the left-hand cooking zone
• 600mm smooth mild steel griddle plate with 2 x 3.4kW heating elements, positioned on the right-hand side as standard
• Radiant elements controlled by energy regulators for precise, stepless heat adjustment
• 20mm thick smooth mild steel griddle plate for superior heat retention and even cooking
• Cooking surface area: 595mm x 530mm
• Total power rating: 11.6kW | 20A/phase max | 3P+N+E | 400-415Vac | 50/60Hz
• Heavy-duty 304 stainless steel construction throughout
• Heavy-duty reinforced control knobs with clear, non-fade markings and strengthened shaft sleeves
• Four stainless steel bench legs with adjustable feet for precise levelling
• Two additional rollers to assist repositioning
• 165mm rear splashback included
• Optional 2kW solid hot plate elements available as an alternative to radiant elements
• Designed for easy cleaning, installation, and servicing
• Modular design compatible with other Blue Seal Evolution Series 900mm units
• Made in New Zealand
• Thermostat temperature range: 90-300°C
• Freestanding installation type

Specifications

• Width (mm): 900
• Depth (mm): 812
• Height (mm): 485
• Weight (kg): 340.0
• Colour: Stainless Steel
• Shipping Weight: 135
• Packed Width (mm): 945.0
• Packed Height (mm): 665.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 0.546730000m3
• Material: 304 Stainless Steel
• Undershelf: N/A (Bench Model)
• Splash Back: Yes (165mm)
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Electric
• Installation Type: Freestanding
• Control Type: Thermostat
• Temperature Control: Thermostat | 90-300°C
• Mounting Type: Freestanding
• Fuel Type: Electric
• Griddle Plate Thickness (mm): 20
• Griddle Surface: Smooth Mild Steel
• Number of Burners: 6
• Cooking Surface Area (mm): 595 x 530
• Power Rating: 11.6 kW|20A/phase max.|3P+N+E|400-415Vac|50/60Hz
• Power Supply: 230-240 Vac | 1P+N+E | 50/60 Hz
• Voltage/Phase: 230-240V | Single Phase
