Blue Seal EP514-B Evolution Series 600mm Electric Griddle – Bench Model

The Blue Seal EP514-B is a 600mm bench-model electric griddle from the Evolution Series, engineered for the demands of busy commercial kitchens. Its 20mm thick mild steel griddle plate delivers outstanding heat retention and even heat distribution across the entire cooking surface, making it ideal for high-volume breakfast service, burgers, seafood and a wide variety of grilled foods.

Constructed in New Zealand from 304 stainless steel, the EP514-B features a solid, seamless top-weld sealed plate construction and precise thermostat control across a single temperature zone, ranging from 90°C to 300°C. The unit is designed with ease of cleaning, installation and servicing in mind, and accepts optional ribbed or chrome mirror plate upgrades to suit different culinary applications.

Key Benefits

• The 20mm thick griddle plate retains heat effectively and distributes it evenly, reducing temperature fluctuations during continuous high-volume cooking.
• A single thermostat control zone covering 90–300°C allows operators to quickly dial in and hold precise cooking temperatures for consistent results across different menu items.
• Top-weld sealed plate construction eliminates gaps where grease and food debris can accumulate, significantly reducing cleaning time between service periods.
• The stainless steel grease drawer collects drippings efficiently and removes cleanly, keeping the work area tidy and speeding up post-service clean-down.
• Adjustable feet and two additional rollers allow the unit to be levelled on uneven surfaces and repositioned with ease during kitchen reconfiguration or cleaning.
• Heavy-duty reinforced control knobs withstand the rigours of a busy kitchen environment, reducing the likelihood of damage from daily use.
• Optional ribbed or chrome mirror plate configurations mean the same unit can be adapted for different cooking styles without replacing the entire appliance.
• Bench-model format with four 63mm diameter heavy-duty 1.2mm stainless steel legs and adjustable height (80–105mm) integrates readily into existing countertop setups.
• A 165mm splashback protects the wall and surrounding equipment from grease splash, reducing cleaning effort and maintaining a safer cooking environment.

Key Features

• 600mm wide bench-model electric griddle from the Blue Seal Evolution Series
• 20mm thick smooth mild steel griddle plate for superior heat retention and even heat distribution
• Cooking surface area: 600mm x 480mm
• Single temperature control zone with thermostat range of 90°C to 300°C
• Four heating elements delivering a total of 7.2kW
• Electrical requirements: 7.2kW, 230–240V AC, 50/60Hz, 1P+N+E, 30A
• Top-weld sealed plate construction for a solid, seamless cooking surface
• Stainless steel grease drawer for easy collection and removal of cooking drippings
• Heavy-duty reinforced control knobs for durability under continuous commercial use
• Four 63mm diameter heavy-duty 1.2mm stainless steel bench legs with adjustable feet
• Adjustable leg height from 80mm to 105mm to suit varying benchtop configurations
• Two additional rollers supplied for easier repositioning of the unit
• 165mm splashback included as standard
• 304 stainless steel body construction
• Optional ribbed mild steel plate or chrome mirror plate available
• Freestanding, bench-mount installation type
• Manufactured in New Zealand

Specifications

• Width (mm): 600
• Depth (mm): 812
• Height (mm): 485
• Weight (kg): 340.0
• Colour: Stainless Steel
• Shipping Weight: 170
• Packed Width (mm): 645.0
• Packed Height (mm): 665.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 0.373165000m3
• Material: 304 Stainless Steel
• Undershelf: N/A (Bench Model)
• Splash Back: Yes (165mm)
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Electric
• Installation Type: Freestanding
• Control Type: Thermostat
• Temperature Control: Thermostat | 90-300°C
• Mounting Type: Freestanding
• Fuel Type: Electric
• Griddle Plate Thickness (mm): 20
• Griddle Surface: Smooth Mild Steel
• Cooking Surface Area (mm): 600 x 480
• Number of Burners: 4
• Power Rating: 1P+N+E|30A|50/60Hz|7.2kW 230-240Vac
• Power Supply: 230-240 Vac | 1P+N+E | 50/60 Hz
• Voltage/Phase: 400-415V 3P+N+E
