Overview

Blue Seal G514B-LS Evolution Series 600mm Gas Griddle Cooktop on Leg Stand

The Blue Seal G514B-LS is a 600mm commercial gas griddle cooktop mounted on a stainless steel leg stand, forming part of the modular Evolution Series designed for high-output hospitality kitchens. Powered by two 20MJ/hr griddle burners delivering a combined 40MJ/hr (11kW), the unit features a 20mm thick smooth mild steel griddle plate with a 595 x 530mm cooking surface, making it well suited to cafés, restaurants, pubs, and hotels that need reliable flat-top cooking capacity during peak service.

Constructed from 304 stainless steel with heavy-duty cast iron burners and vitreous enamel pot stands, the G514B-LS is built to handle the rigours of daily commercial use. Push-button piezo ignition and flame failure protection on all burners simplify start-up and enhance safety, while the open leg stand configuration keeps the floor accessible for cleaning and allows flexible under-unit storage. The unit integrates seamlessly with other Blue Seal Evolution Series equipment for a matched suite configuration and is available in both Natural Gas and LPG.

Key Benefits

• Consistent flat-top heat across a large 595 x 530mm smooth griddle surface suits high-volume breakfast, burger, and grill menus.
• Push-button piezo ignition on the griddle allows fast, tool-free start-up at the beginning of each service.
• Flame failure protection on all burners automatically cuts gas if a flame is extinguished, reducing safety risks in busy kitchens.
• Heavy-duty reinforced control knobs with clear, non-fade markings allow precise heat adjustment from high to low simmer without knob wear or replacement.
• Open leg stand design keeps the floor beneath the unit fully accessible for mopping and hygiene compliance, while also providing flexible under-unit storage space.
• Adjustable stainless steel feet and two rear rollers make levelling straightforward and allow the unit to be repositioned for servicing or cleaning.
• Removable cast iron burners and vitreous enamel pot stands simplify daily cleaning and routine maintenance without specialist tools.
• Modular Evolution Series format allows the G514B-LS to be paired with matching Blue Seal suite components, including a 165mm splashback and undershelf, for a cohesive kitchen layout.
• Available in Natural Gas or LPG configurations, offering flexibility to suit existing kitchen utility connections.

Key Features

• 600mm wide gas griddle cooktop on stainless steel leg stand
• 2 x 20MJ/hr griddle burners; combined gas rating 40MJ/hr (11kW)
• 20mm thick smooth mild steel griddle plate
• Griddle cooking surface area: 595 x 530mm
• Push-button piezo ignition on griddle burners
• Flame failure protection on all burners
• Removable heavy-duty cast iron burners with forged brass caps for consistent flame spread and non-clogging performance
• Vitreous enamel cast iron pot stands with extended finger supports for small pan stability
• 304 stainless steel construction throughout
• Heavy-duty reinforced control knobs with clear, non-fade markings and strengthened shaft sleeves
• Four stainless steel bench legs with adjustable feet for precise levelling
• Two rear rollers for repositioning during cleaning or servicing
• 165mm splashback included
• Suite-matching undershelf included
• Freestanding, open leg stand configuration for floor access and under-unit storage
• Available in Natural Gas or LPG — specify gas type when ordering
• R 3/4 (BSP) male gas connection
• Part of the modular Blue Seal Evolution Series for matched suite integration
• Made in New Zealand

Specifications

• Width (mm): 600
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 116
• Packed Width (mm): 645.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 0.704243000m3
• Material: 304 Stainless Steel
• Undershelf: Yes (Suite Matching)
• Splash Back: Yes (165mm)
• No. of Shelves: 1
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Installation Type: Freestanding
• Control Type: Thermostat
• Temperature Control: Thermostat | 90-300°C
• Mounting Type: Freestanding
• Fuel Type: Gas
• Griddle Plate Thickness (mm): 20
• Griddle Surface: Smooth Mild Steel
• Cooking Surface Area (mm): 595 x 530
• Number of Burners: 4
• Power Rating: 304 Stainless Steel
• Power Supply: N/A (Gas)
• Voltage/Phase: N/A (Gas)
