Overview

Blue Seal G514C-B Evolution Series 600mm Gas Cooktop with Griddle - Bench Model

The Blue Seal G514C-B is a 600mm bench model gas cooktop from the Evolution Series, combining two high-output 28MJ/hr open burners with a 300mm smooth mild steel griddle plate powered by a dedicated 20MJ/hr griddle burner. Built from 304 stainless steel and manufactured in New Zealand, this unit is engineered specifically for the rigorous demands of commercial kitchens in cafes, restaurants, hotels, and pubs. The griddle is positioned on the right-hand side as standard, and the unit accepts both natural gas and LPG connections.

Designed for straightforward integration into modular Blue Seal Evolution Series cooking suites or standalone bench installation, the G514C-B features flame failure protection across all burners, push-button piezo ignition on the griddle, and removable heavy-duty cast iron burners with vitreous enamel pot stands. A 165mm splashback, four stainless steel legs with adjustable feet, and two rear rollers make positioning and daily service practical in any commercial kitchen environment.

Key Benefits

• Two 28MJ/hr open burners deliver rapid, responsive heat for boiling, sautéing, and stockpot work, helping kitchen teams move through peak service efficiently.
• A dedicated 20MJ/hr griddle burner with a 20mm thick smooth mild steel plate provides consistent, even surface heat for grilling and breakfast service.
• Flame failure protection on every burner automatically cuts gas flow if a flame extinguishes, supporting kitchen safety compliance.
• Push-button piezo ignition on the griddle allows fast, reliable start-up without the need for a separate ignition source.
• Removable cast iron burners and vitreous enamel pot stands simplify cleaning and reduce downtime during service.
• Adjustable stainless steel feet and two rear rollers allow precise levelling and easy repositioning for cleaning or reconfiguration.
• Modular Evolution Series compatibility means the unit can be integrated into a full cooking suite alongside other Blue Seal equipment, maximising bench and floor space.
• Heavy-duty reinforced control knobs with clear, non-fade markings provide precise heat adjustment from high to low simmer, reducing the need for knob replacement over time.
• Available in natural gas and LPG configurations, giving flexibility across different commercial kitchen setups.

Key Features

• 2-burner cooktop combined with a 300mm right-hand griddle in a single 600mm bench model unit
• 2 x 28MJ/hr open burners for high-output cooking across a range of techniques
• 1 x 20MJ/hr dedicated griddle burner; total gas rating 76MJ/hr (21kW)
• 20mm thick smooth mild steel griddle plate with a cooking surface area of 295 x 530mm
• Griddle positioned on the right-hand side as standard
• Flame failure protection on all burners for gas safety
• Push-button piezo ignition on the griddle burner
• Removable heavy-duty cast iron burners with forged brass caps for consistent, non-clogging flame spread
• Vitreous enamel pot stands with extended finger supports to stabilise smaller pans and prevent tip-overs
• 304 stainless steel construction throughout
• Heavy-duty reinforced control knobs with strengthened shaft sleeves and clear, non-fade markings
• 165mm rear splashback included
• Four stainless steel bench legs with adjustable feet for precise levelling
• Two rear rollers for easy repositioning
• R 3/4 (BSP) male gas connection
• Available in natural gas or LPG; specify at time of ordering
• Part of the modular Blue Seal Evolution Series, compatible with 300, 450, 600, 900, and 1200mm griddle configurations
• Freestanding bench model; no undershelf
• Country of origin: New Zealand
• Easy-clean and easy-service design with accessible burner components

Specifications

• Width (mm): 600
• Depth (mm): 812
• Height (mm): 485
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 116
• Packed Width (mm): 1170.0
• Packed Height (mm): 665.0
• Packed Depth (mm): 350.0
• Shipping Cubic: 0.272318000m3
• Material: 304 Stainless Steel
• Undershelf: N/A (Bench Model)
• Splash Back: Yes (165mm)
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Installation Type: Freestanding
• Control Type: Thermostat
• Temperature Control: Thermostat | 90-300°C
• Mounting Type: Freestanding
• Fuel Type: Gas
• Griddle Plate Thickness (mm): 20
• Griddle Surface: Smooth Mild Steel
• Cooking Surface Area (mm): 295 x 530
• Number of Burners: 2
• Power Rating: 304 Stainless Steel
• Power Supply: N/A (Gas)
• Voltage/Phase: N/A (Gas)
