Overview

Blue Seal G514C-LS Evolution Series 600mm Gas Combination Cooktop with 300mm Griddle on Leg Stand

The Blue Seal G514C-LS Evolution Series delivers serious commercial cooking performance in a compact 600mm footprint, combining two powerful 28MJ/hr open burners with a 300mm smooth mild steel griddle plate on a freestanding stainless steel leg stand. Manufactured in New Zealand from 304 stainless steel, this unit is built to withstand the daily rigours of high-volume professional kitchens, offering a combined gas rating of 76MJ/hr (21kW) across all three burners.

Designed for operational convenience, the G514C-LS features flame failure protection on every burner, push-button piezo ignition on the griddle, and heavy-duty cast iron burners with vitreous enamel pot stands for consistent, reliable heat delivery. Removable components, adjustable feet, and two additional rollers make cleaning, repositioning, and routine servicing straightforward. Available in both Natural Gas and LPG configurations to suit your kitchen's supply.

Key Benefits

• Two 28MJ/hr open burners deliver high-output heat for rapid boiling, searing, and large-batch cooking, helping kitchens turn out orders faster.
• A 300mm smooth mild steel griddle at 20MJ/hr provides a versatile, even cooking surface for eggs, proteins, and breakfast items alongside open-flame cooking.
• Flame failure protection on all burners automatically cuts gas flow if a flame extinguishes, improving safety for kitchen staff.
• Push-button piezo ignition on the griddle allows quick, reliable lighting without a separate ignition source, reducing downtime during service.
• Extended-finger vitreous enamel pot stands add stability when sliding smaller pots and pans across the cooktop, reducing the risk of tip-overs.
• Adjustable feet and two integrated rollers make it easy to level the unit on uneven floors and reposition it during cleaning or kitchen reconfiguration.
• Heavy-duty reinforced control knobs with non-fade markings allow precise heat adjustment from high to simmer, and strengthened shaft sleeves extend the service life of controls.
• Removable cast iron burners and vitreous enamel pot stands simplify daily cleaning and reduce maintenance time.
• A 165mm splashback and matching undershelf are included, keeping the surrounding workspace cleaner and providing additional storage or prep space beneath the unit.

Key Features

• 2 x 28MJ/hr heavy-duty cast iron open burners with forged brass caps for consistent, non-clogging flame spread
• 1 x 20MJ/hr griddle burner with 300mm smooth mild steel griddle plate, 20mm thick, positioned on the right-hand side as standard
• Total combined gas rating: 76MJ/hr (21kW) across all three burners
• Flame failure protection fitted to all burners as a standard safety feature
• Push-button piezo ignition on the griddle burner for fast, reliable lighting
• Removable cast iron burners and vitreous enamel pot stands for straightforward cleaning and replacement
• Heavy-duty reinforced control knobs with clear, non-fade markings and strengthened shaft sleeves for long service life
• Thermostat temperature control on griddle: 90-300°C range
• 304 stainless steel construction throughout for durability and corrosion resistance
• Four stainless steel bench legs with adjustable feet for levelling on uneven surfaces
• Two additional rollers integrated into the leg stand for easy repositioning
• 165mm splashback included
• Suite-matching undershelf included, providing one additional storage shelf
• Freestanding installation on leg stand; overall height including splashback 1085mm
• Gas connection: R 3/4 (BSP) male fitting
• Compatible with Natural Gas or LPG (specify gas type at time of ordering)
• Griddle surface: smooth mild steel, cooking surface area 295 x 530mm
• Country of origin: New Zealand

Specifications

• Width (mm): 600
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 116
• Packed Width (mm): 645.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 0.704243000m3
• Material: 304 Stainless Steel
• Undershelf: Yes (Suite Matching)
• Splash Back: Yes (165mm)
• No. of Shelves: 1
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Installation Type: Freestanding
• Control Type: Thermostat
• Temperature Control: Thermostat | 90-300°C
• Mounting Type: Freestanding
• Fuel Type: Gas
• Griddle Plate Thickness (mm): 20
• Griddle Surface: Smooth Mild Steel
• Cooking Surface Area (mm): 295 x 530
• Number of Burners: 2
• Power Rating: 304 Stainless Steel
• Power Supply: N/A (Gas)
• Voltage/Phase: N/A (Gas)
