Overview

Blue Seal G514D-CB Evolution Series 600mm Gas Cooktop with Cabinet Base

The Blue Seal G514D-CB is a 600mm commercial gas cooktop from the Evolution Series, mounted on a fully enclosed stainless steel cabinet base with a single hinged door. Designed and built in New Zealand from 304 stainless steel, it suits cafes, restaurants, pubs, and hotels that need serious multi-burner output in a compact footprint. Four open burners each rated at 28MJ/hr deliver a combined gas rating of 112MJ/hr, giving kitchen teams the raw heat needed for boiling, simmering, sauteing, and stockpot work through peak service.

Heavy-duty cast iron burners with forged brass caps ensure consistent flame spread and long-term durability under daily commercial punishment, while vitreous enamel pot stands feature extended finger supports so smaller pans can be slid across the surface without tipping. Flame failure protection on every burner adds an essential safety layer, and reinforced control knobs with non-fade markings allow precise adjustment from full heat down to a gentle simmer. The enclosed cabinet base provides practical underbench storage, adjustable feet keep the unit level on uneven floors, and two rear rollers make repositioning straightforward. As part of the fully modular Evolution Series, this unit integrates seamlessly into complete Blue Seal kitchen suites.

Key Benefits

• Four 28MJ/hr open burners deliver 112MJ/hr combined output, so large volumes of food reach temperature quickly during high-demand service periods.
• Flame failure protection on all burners automatically cuts gas flow if a flame is extinguished, reducing safety risks in busy kitchen environments.
• Extended finger supports on the vitreous enamel pot stands create a more uniform cooking surface, preventing smaller pots and pans from tipping during use.
• The enclosed cabinet base provides organised underbench storage for cookware, trays, and utensils, improving kitchen workflow without consuming extra floor space.
• Forged brass burner caps promote even, consistent flame spread across the cooking surface, supporting precise heat control for delicate and heavy-duty tasks alike.
• Adjustable feet combined with two rear rollers make levelling simple and allow the unit to be moved for cleaning or repositioning without heavy lifting.
• Reinforced control knobs with non-fade markings and strengthened shaft sleeves withstand constant daily use, reducing the need for frequent replacement.
• Removable cast iron burners and a design focused on easy cleaning and servicing help minimise downtime and keep maintenance costs low.
• Full compatibility with the Blue Seal Evolution Series modular system allows this cooktop to be paired with other 600mm, 900mm, or 1200mm suite components for a cohesive kitchen line-up.

Key Features

• 4 x 28MJ/hr open gas burners, totalling 112MJ/hr (31kW) combined gas rating
• Heavy-duty cast iron burners with forged brass caps for consistent, even flame spread
• Non-clogging burner design for reliable, optimum burner performance over time
• Vitreous enamel cast iron pot stands with extended finger supports to stabilise smaller pots and pans
• Flame failure protection fitted to all four burners as a standard safety feature
• Heavy-duty reinforced control knobs with non-fade markings and strengthened shaft sleeves for lasting precision
• Fully enclosed 304 stainless steel cabinet base with single hinged door for underbench storage
• 165mm stainless steel splashback included; overall height including splashback is 1085mm
• Constructed from 304 stainless steel throughout for hygiene and corrosion resistance
• Adjustable feet for levelling on uneven floors, plus 2 rear rollers for easy repositioning
• Removable cast iron burner assemblies for straightforward cleaning and servicing
• Available in Natural Gas or LPG; gas connection is R 3/4 (BSP) male
• Compatible with 300mm to 1200mm smooth or ribbed mild steel griddle plates (sold separately)
• Fully modular Evolution Series design for integration into complete Blue Seal commercial kitchen suites
• Freestanding installation type; manual knob variable power control
• Manufactured in New Zealand

Specifications

• Width (mm): 600
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 116
• Packed Width (mm): 645.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 0.704243000m3
• Material: 304 Stainless Steel
• Undershelf: Cabinet Base
• Door Type: Hinged
• Splash Back: Yes (165mm)
• No. of Doors: 1
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Installation Type: Freestanding
• Control Type: Manual Knob
• Temperature Control: Variable Power Control
• Mounting Type: Freestanding
• Fuel Type: Gas
• Number of Burners: 4
• Cooking Surface Area (mm): 600 x 480
• Power Rating: 304 Stainless Steel
• Power Supply: N/A (Gas)
• Voltage/Phase: N/A (Gas)
