Overview

Blue Seal G516A-LS Evolution Series 900mm Gas Cooktop on Leg Stand

The Blue Seal G516A-LS is a heavy-duty 900mm gas griddle cooktop mounted on a leg stand, built as part of the Evolution Series for demanding commercial kitchen environments. Manufactured in New Zealand from 304 stainless steel, it features three 20MJ/hr griddle burners delivering a combined gas rating of 60MJ/hr (16.6kW) across a large smooth mild steel cooking surface, making it well suited to high-volume breakfast, brunch and grill-focused service.

Designed for both ease of use and long-term reliability, the G516A-LS incorporates flame failure protection on all burners, push-button piezo ignition, and removable heavy-duty cast iron burners with vitreous enamel pot stands. Adjustable feet and two additional rollers allow straightforward repositioning within the kitchen, while a suite-matching undershelf, 165mm splashback and accessible component design support efficient cleaning and servicing. Available in natural gas or LPG configuration.

Key Benefits

• Three 20MJ/hr griddle burners provide powerful, consistent heat across the full 892 x 530mm smooth mild steel cooking surface, supporting fast, high-volume grilling and frying.
• Flame failure protection on every burner automatically cuts the gas supply if a flame is extinguished, reducing risk during busy service periods.
• Push-button piezo ignition allows quick, tool-free startup without the need for a separate lighter, saving time during kitchen setup.
• Removable cast iron burners and vitreous enamel pot stands are straightforward to lift out for thorough cleaning, reducing downtime between services.
• Adjustable feet combined with two additional rollers make it easy to level the unit on uneven floors and reposition it for cleaning or kitchen reconfiguration.
• A 20mm thick smooth mild steel griddle plate retains heat effectively and provides an even cooking surface for a wide range of ingredients.
• 304 stainless steel construction throughout resists corrosion and stands up to the rigours of daily commercial use, supporting a long service life.
• Compatible with both natural gas and LPG, giving flexibility for different site configurations with a 3/4 BSP male gas connection.
• Suite-matching undershelf and 165mm splashback integrate neatly with other Evolution Series equipment for a cohesive, functional kitchen line.

Key Features

• 900mm wide smooth mild steel griddle cooking surface measuring 892 x 530mm
• 3 x 20MJ/hr griddle burners; combined gas rating 60MJ/hr (16.6kW)
• 20mm thick griddle plate for superior heat retention and even cooking
• Flame failure protection fitted to all burners as standard
• Push-button piezo ignition on the griddle for reliable, easy lighting
• Removable heavy-duty cast iron burners for straightforward cleaning and servicing
• Vitreous enamel pot stands for durability and easy surface cleaning
• Heavy-duty reinforced control knobs designed to withstand repeated daily use
• Adjustable feet and 2 additional rollers for levelling and mobility
• 304 stainless steel construction throughout
• 165mm splashback included
• Suite-matching undershelf (1 shelf)
• Freestanding leg stand configuration; unit height 1085mm including splashback
• 3/4 BSP male gas connection
• Available in natural gas or LPG; gas type must be specified at time of order
• Thermostat temperature control ranging from 90°C to 300°C
• Manufactured in New Zealand

Specifications

• Width (mm): 900
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 396.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 174
• Packed Width (mm): 945.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 1.031798000m3
• Material: 304 Stainless Steel
• Undershelf: Yes (Suite Matching)
• Splash Back: Yes (165mm)
• No. of Shelves: 1
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Installation Type: Freestanding
• Control Type: Thermostat
• Temperature Control: Thermostat | 90-300°C
• Mounting Type: Freestanding
• Fuel Type: Gas
• Griddle Plate Thickness (mm): 20
• Griddle Surface: Smooth Mild Steel
• Cooking Surface Area (mm): 892 x 530
• Number of Burners: 6
• Power Rating: 304 Stainless Steel
• Power Supply: N/A (Gas)
• Voltage/Phase: N/A (Gas)
