Blue Seal G516C-CB Evolution Series 900mm Gas Cooktop with Cabinet Base

The Blue Seal G516C-CB is a 900mm commercial gas cooktop from the Evolution Series, pairing four high-output 28MJ/hr open burners with a 300mm right-hand griddle, all mounted on a fully enclosed stainless steel cabinet base. With a total gas rating of 132MJ/hr (36.6kW), it is built to meet the demands of restaurants, cafes, hotels, and high-volume hospitality kitchens, handling everything from rapid boiling to precise simmering.

Heavy-duty cast iron burners with forged brass caps, vitreous enamel pot stands featuring extended finger supports, and flame failure protection on every burner ensure reliable performance through the rigours of daily commercial service. The 20MJ/hr griddle burner ignites via push-button piezo ignition, the enclosed cabinet base offers practical underbench storage, and the unit is available in Natural Gas or LPG configurations. This cooktop is designed to slot into a complete kitchen suite alongside other units within the Blue Seal Evolution Series modular range.

Key Benefits

• Four 28MJ/hr open burners deliver rapid, responsive heat for boiling, sauteing, simmering, and high-volume stockpot cooking during peak service.
• An integrated 300mm griddle with a dedicated 20MJ/hr burner expands cooking versatility without requiring additional floor equipment.
• Flame failure protection on all burners automatically cuts the gas supply if a flame extinguishes, enhancing kitchen safety.
• Forged brass burner caps promote consistent flame spread, and the non-clogging burner design maintains optimum performance over time.
• Extended finger supports on vitreous enamel pot stands stabilise smaller pots and pans, reducing the risk of tip-overs during busy service.
• The enclosed cabinet base provides valuable underbench storage for cookware and trays, improving kitchen organisation and workflow.
• Adjustable feet and two rear rollers make levelling straightforward and allow the unit to be repositioned easily for cleaning and servicing.
• Reinforced control knobs with non-fade markings and strengthened shaft sleeves allow precise heat adjustment and resist daily wear.
• The removable heavy-duty cast iron burners and separate vitreous enamel pot stands can each be lifted out independently, simplifying cleaning and routine maintenance to reduce kitchen downtime.

Key Features

• 900mm wide cooktop configuration: 4 open burners plus 300mm griddle on an enclosed cabinet base
• 4 x 28MJ/hr cast iron open burners with forged brass caps for consistent, even flame spread
• 1 x 20MJ/hr griddle burner with push-button piezo ignition; griddle positioned on the right-hand side as standard
• Total gas rating: 132MJ/hr (36.6kW)
• Flame failure protection fitted to all burners
• Removable heavy-duty cast iron burners for ease of cleaning and replacement
• Vitreous enamel cast iron pot stands with extended finger supports for added small-pan stability
• Heavy-duty stainless steel construction throughout
• Fully enclosed stainless steel cabinet base with integrated underbench storage
• Heavy-duty reinforced control knobs with non-fade markings and strengthened shaft sleeves
• Adjustable feet plus 2 rear rollers for levelling and repositioning
• Griddle plate options available in smooth or ribbed finishes, machine-finished in mild steel, across 300, 450, 600, 900, or 1200mm sizes
• Available in Natural Gas or LPG; gas type must be specified at time of order
• Designed to integrate into complete kitchen suites as a component of the Blue Seal Evolution Series modular system
• Designed for easy cleaning, installation, and servicing
• 2 years parts and labour warranty

Specifications

• Width (mm): 900
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 396.0
• Shipping Weight: 245
• Packed Width (mm): 945.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 1.031798000m3
