Blue Seal G516D-CB Evolution Series 900mm Gas Cooktop with Cabinet Base

The Blue Seal G516D-CB is a 900mm commercial gas cooktop from the Evolution Series, mounted on a fully enclosed stainless steel cabinet base with a single hinged door. Designed and manufactured in New Zealand from 304 stainless steel, it delivers a total output of 168MJ/hr across six open burners, making it well suited to high-volume restaurants, cafés, hotels, pubs, and institutional kitchens where consistent cooking power and durable construction are non-negotiable.

Each burner features a heavy-duty cast iron body with a forged brass cap for consistent flame spread and a non-clogging design, paired with thick vitreous enamel pot stands that include extended finger supports to stabilise smaller pans during busy service. Flame failure protection on every burner, reinforced heat-resistant control knobs, removable spill trays, adjustable stainless steel feet, and two rear rollers combine to make the G516D-CB straightforward to operate, clean, and service in demanding commercial kitchen environments. As a modular unit it integrates directly into complete Blue Seal Evolution Series kitchen suites.

Key Benefits

• Six 28MJ/hr open burners deliver a total 168MJ/hr of cooking power, enabling rapid boiling, sautéing, simmering, and stockpot work across all positions simultaneously.
• Forged brass burner caps promote even, consistent flame spread across the cooking zone, reducing hot spots and improving heat control from high to gentle simmer.
• Extended finger supports on the vitreous enamel pot stands add stability for smaller pots and pans, reducing tip-over risk during fast-paced service.
• Flame failure protection on every burner automatically cuts gas flow if a flame is extinguished, improving safety for kitchen staff.
• The enclosed cabinet base with hinged door provides valuable underbench storage for cookware, trays, and utensils, keeping the workspace organised and improving service efficiency.
• Adjustable stainless steel feet and two rear rollers make positioning and levelling straightforward, and allow easy repositioning for cleaning or maintenance.
• Removable cast iron burners, vitreous enamel pot stands, and stainless steel spill trays simplify daily cleaning and reduce downtime between services.
• Available in both natural gas and LPG configurations, offering flexibility for different site gas supplies without compromising performance.
• Modular 900mm footprint aligns with other Blue Seal Evolution Series units, allowing a coherent, space-efficient commercial kitchen suite to be assembled to suit any layout.

Key Features

• Six x 28MJ/hr heavy-duty open gas burners with a combined total output of 168MJ/hr (46.6kW)
• Cast iron burners with forged brass caps for consistent, non-clogging flame spread
• Flame failure protection fitted to all six burners as standard
• Thick vitreous enamel cast iron pot stands with extended finger supports for pan stability
• Removable cast iron burners and pot stands for straightforward cleaning and replacement
• Heavy-duty reinforced, heat-resistant control knobs with clear, non-fade markings and strengthened shaft sleeves
• Variable manual knob control across the full heat spectrum from high to simmer
• Constructed from 304 stainless steel throughout
• Fully enclosed stainless steel cabinet base with single hinged door providing integrated underbench storage
• 165mm rear splashback included
• Removable stainless steel spill trays for easy cleaning
• Adjustable stainless steel feet and two rear rollers for levelling and repositioning
• Freestanding, modular installation compatible with the Blue Seal Evolution Series suite
• Available in natural gas or LPG - specify gas type at time of order
• R 3/4 (BSP) male gas connection
• Optional cast iron simmer plates available (not included as standard)
• Compatible with 300, 450, 600, 900, and 1200mm griddle plates in smooth or ribbed mild steel (not included)
• Manufactured in New Zealand
• Dimensions: 900mm (W) x 812mm (D) x 1085mm (H) including splashback; cabinet base height 915mm without splashback

Specifications

• Width (mm): 900
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 396.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 245
• Packed Width (mm): 945.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 1.031798000m3
• Material: 304 Stainless Steel
• Undershelf: Cabinet Base
• Door Type: Hinged
• Splash Back: Yes (165mm)
• No. of Doors: 1
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Installation Type: Freestanding
• Control Type: Manual Knob
• Temperature Control: Variable Power Control
• Mounting Type: Freestanding
• Fuel Type: Gas
• Number of Burners: 6
• Cooking Surface Area (mm): 900 x 480
• Power Rating: 304 Stainless Steel
• Power Supply: N/A (Gas)
• Voltage/Phase: N/A (Gas)
