Blue Seal G56A Evolution Series 900mm Gas Range Convection Oven

The Blue Seal G56A Evolution Series is a 900mm wide commercial gas range combining a heavy-duty griddle section with an integrated GN 2/1 fan-assisted gas convection oven, delivering versatile multi-zone cooking from a single freestanding unit. Powered by 3 x 20MJ/hr griddle burners and rated at a total gas input of 90MJ/hr (25kW), it suits high-volume restaurants, cafes, bakeries and catering operations that need to grill, fry and bake simultaneously without compromise.

Engineered in New Zealand to Blue Seal's Evolution Series standards, the G56A is constructed from heavy-duty 304 stainless steel with removable cast iron burners, vitreous enamel pot stands and a fully welded and vitreous enamelled oven liner for durability and straightforward cleaning. Flame failure protection on every burner, a cool-touch door handle, thermostatic oven control between 50°C and 320°C, and a 3-pin 10A plug cordset make it a safe, practical and low-maintenance choice for busy commercial kitchens.

Key Benefits

• Fan-assisted convection circulation delivers consistent, even heat throughout the GN 2/1 oven cavity, reducing cooking times and allowing food to be cooked at lower temperatures for better results
• Multi-zone operation lets kitchen staff grill or fry on the griddle while simultaneously roasting or baking in the oven below, increasing throughput without requiring additional equipment
• Flame failure protection on all burners automatically cuts gas flow if a flame is extinguished, reducing risk and supporting compliance with commercial kitchen safety requirements
• Cast iron sole plates inside the oven ensure even heat distribution across the cavity floor, minimising hot spots and improving batch cooking consistency
• The vitreous enamelled oven liner and removable cast iron burner components simplify daily cleaning and reduce maintenance downtime between services
• Adjustable feet combined with two rear rollers make levelling and repositioning straightforward during installation or when reconfiguring a kitchen layout
• Heavy-duty reinforced control knobs and a drop-down door with welded frame are built to withstand the physical demands of continuous commercial use
• Available in both Natural Gas and LPG configurations, giving operators flexibility to match their existing gas supply without modification

Key Features

• 900mm wide freestanding gas range with integrated griddle and convection oven sections
• GN 2/1 fan-assisted gas convection oven with heavy-duty motor and circulation fan
• Thermostatic oven temperature control from 50°C to 320°C
• 3 x 20MJ/hr griddle burners; total gas rating 90MJ/hr (25kW)
• Removable heavy-duty cast iron burners with vitreous enamel pot stands
• Cast iron sole plates in the oven cavity for even heat distribution
• Fully welded and vitreous enamelled oven liner for easy cleaning and long-term durability
• Flame failure protection on all burners
• Drop-down oven door with welded frame
• Cool-touch stainless steel door handle
• Heavy-duty reinforced control knobs
• 165mm splashback included; overall height including splashback 1085mm; bench height (without splashback) 915mm
• Heavy-duty 304 stainless steel exterior finish
• Adjustable feet with 2 additional rear rollers for levelling and repositioning
• Power supply: 220-240V single phase, 50Hz; 3-pin 10A plug cordset fitted
• Available in Natural Gas or LPG; R 3/4 (BSP) male gas connection
• Freestanding installation type
• Country of origin: New Zealand

Specifications

• Width (mm): 900
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 396.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 275
• Packed Width (mm): 945.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 1.031798000m3
• Material: 304 Stainless Steel
• Undershelf: N/A (Integrated Oven)
• Door Type: Drop Down
• Splash Back: Yes (165mm)
• No. of Shelves: 2
• No. of Doors: 1
• Country of Origin: New Zealand
• Warranty (months): 12
• Capacity (Litres): 2
• Temperature Range: Gas
• Installation Type: Freestanding
• Control Type: Manual Knob
• Temperature Control: Thermostat | 90-300°C
• Mounting Type: Freestanding
• Fuel Type: Gas / Electric
• Griddle Plate Thickness (mm): 12
• Griddle Surface: Smooth Mild Steel (Ribbed or Chrome Optional)
• Cooking Surface Area (mm): 900 x 480
• Number of Burners: 6
• Power Supply: 220-240 Vac | 1P+N+E | 50Hz
• Voltage/Phase: 220-240V | Single Phase
