Overview

Blue Seal G594-B Evolution Series 600mm Gas Chargrill – Bench Model

The Blue Seal G594-B is a 600mm bench model gas chargrill from the Evolution Series, built for high-volume commercial kitchens that require consistent, intense grilling performance. Manufactured in New Zealand from 304 stainless steel throughout, it is powered by two thermostatic burners rated at 33 MJ/hr each, fitted with stainless steel U-burners and radiant elements that generate maximum heat to seal in meat flavours and produce authentic char marks across a 600 x 480mm cooking surface.

Practical kitchen operation is central to the G594-B's design. Reversible heavy-duty cast iron grates feature a grooved fin pattern and can be set level or inclined, directing grease toward a front collection channel to reduce flare-ups. Drop-on 300mm and 450mm griddle sections are fully interchangeable with the grates for added cooking versatility. Internal components including the radiants, burners and grease tray baffles are all removable for straightforward cleaning and routine servicing. The unit is available in natural gas and LPG configurations and suits kitchens with existing cabinetry or custom fabrication as part of a modular Evolution Series suite.

Key Benefits

• Each of the two 33 MJ/hr thermostatic burners delivers precise, high-output heat, ensuring consistent grilling results across the full cooking surface.
• Reversible cast iron grates switch between level and inclined positions, giving chefs the flexibility to adapt to different menu items and cooking techniques.
• When set to the inclined position, the grooved fin grate design channels grease into a front collection channel, significantly reducing flare-ups and improving cook quality.
• Every burner is equipped with individual pilot ignition and automatic gas shut-off on flame loss, providing continuous safety monitoring throughout service.
• Interchangeable drop-on 300mm and 450mm griddle sections expand cooking capability without requiring additional equipment.
• Removable internal components — the radiants, burners and grease tray baffles — allow fast access for daily cleaning and routine servicing, reducing downtime.
• Heavy-duty reinforced control knobs are built to withstand the rigours of continuous commercial use.
• The bench model format offers flexible placement within a suite of modular Evolution Series equipment, suiting kitchens with existing cabinetry or custom fabrication.

Key Features

• 600mm wide bench model configuration; no undershelf
• Two independent 33 MJ/hr thermostatic burners with stainless steel U-burners
• Stainless steel burners and radiant elements for maximum heat generation
• Reversible heavy-duty cast iron top grates – usable level or inclined
• Grooved fin grate design channels grease to a front collection channel when inclined
• Compatible with drop-on 300mm and 450mm griddle sections interchangeable with the grates
• Individual pilot ignition and automatic gas shut-off on flame loss for each burner
• Removable radiants, burners and grease tray baffles for easy-access cleaning
• Heavy-duty reinforced control knobs
• 165mm splashback included
• 304 stainless steel construction throughout
• Gas connection: R 3/4 (BSP) male
• Available in natural gas or LPG – specify at time of ordering
• Freestanding installation type
• Manufactured in New Zealand
• Note: product images may depict the G594-LS model

Specifications

• Width (mm): 600
• Depth (mm): 812
• Height (mm): 585
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 133
• Packed Width (mm): 645.0
• Packed Height (mm): 1225.0
• Packed Depth (mm): 945.0
• Shipping Cubic: 0.746668000m3
• Material: 304 Stainless Steel
• Undershelf: N/A (Bench Model)
• Splash Back: Yes (165mm)
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Installation Type: Freestanding
• Control Type: Thermostat
• Mounting Type: Freestanding
• Fuel Type: Gas
• Griddle Plate Thickness (mm): 20
• Griddle Surface: Smooth Mild Steel
• Cooking Surface Area (mm): 600 x 480
• Number of Burners: 2
• Power Rating: 304 Stainless Steel
• Power Supply: N/A (Gas)
• Voltage/Phase: N/A (Gas)
