Overview

Blue Seal G596-LS Evolution Series 900mm Gas Chargrill on Leg Stand

The Blue Seal G596-LS Evolution Series 900mm Gas Chargrill on Leg Stand is a heavy-duty, freestanding gas chargrill engineered for high-volume commercial kitchens. Built in New Zealand from 304 stainless steel, it delivers a total output of 100 MJ/hr (29.3 kW) across three independently controlled 33 MJ/hr thermostatic burner zones, each covering a 300mm section of the 900 x 480mm cooking surface. Available in Natural Gas or LPG configurations, it integrates seamlessly into a matched Blue Seal Evolution Series suite.

Designed for ease of service and genuine operational flexibility, the G596-LS features reversible heavy-duty top grates that can be set level or inclined to reduce flare-ups and channel grease efficiently into a front collection point. All radiants, burners, and grease tray baffles lift out for thorough cleaning, while the fully modular framed leg stand includes a matching undershelf, a 165mm splashback, 63mm diameter 304 stainless steel legs with two adjustable front feet, and two rear rollers for straightforward repositioning.

Key Benefits

• Three independently controlled burner zones allow sections to be run at different temperatures simultaneously, reducing energy use during quieter service periods.
• Reversible top grates switch between level and inclined positions, letting operators minimise flare-ups and direct grease runoff away from the cooking zone for safer, cleaner grilling.
• Per-burner flame failure protection with a continuous pilot on each zone shuts off gas automatically if a flame extinguishes, supporting kitchen safety compliance.
• A total output of 100 MJ/hr across the 900mm surface delivers intense, consistent radiant heat to sear meats quickly and achieve authentic char marks.
• Lift-out grates, radiants, burners, and grease tray baffles make end-of-service cleaning faster and more thorough, reducing downtime between shifts.
• Heavy-duty reinforced control knobs withstand the rigours of continuous commercial use and remain easy to operate even with wet or greasy hands.
• Two front adjustable feet and two rear rollers allow precise levelling on uneven floors and easy movement for behind-unit cleaning or reconfiguration.
• Fully modular construction is compatible with the wider Blue Seal Evolution Series suite, enabling a consistent bench height and matched stainless steel finish across the line.
• 304 stainless steel construction throughout the stand, shelf, and legs resists corrosion and simplifies surface sanitation in demanding kitchen environments.

Key Features

• 900mm wide gas chargrill mounted on a matching leg stand
• 3 x 33 MJ/hr thermostatic burner system; total gas rating 100 MJ/hr (29.3 kW)
• 304 stainless steel U-burners
• Cooking surface area: 900mm x 480mm
• Reversible heavy-duty top grates — set level or inclined to reduce flare and enhance grease runoff
• Inclined grate position channels grease into a front collection channel
• Individual hi-lo gas control per burner with full flame failure protection and continuous pilot burner per zone
• Lift-out grates, radiants, burners, and grease tray baffles for easy cleaning and servicing
• Grooved fins on radiants assist heat distribution and grease management
• Interchangeable griddle sections available in 300mm and 450mm configurations for added versatility
• Heavy-duty reinforced control knobs
• 63mm diameter, 1.2mm 304 stainless steel legs with two adjustable feet at the front and two rear rollers
• Fully modular framed stand with 0.9mm 304 stainless steel shelf finish
• Matching undershelf included
• 165mm rear splashback
• Freestanding, freestanding installation type
• Gas connection: R 3/4 (BSP) male
• Available in Natural Gas or LPG — specify gas type at time of ordering
• Height including splashback: 1085mm; stand height to cooking surface: 915mm
• Fully modular for matched Evolution Series suite finish
• Manufactured in New Zealand
• Body and stand constructed from 304 stainless steel

Specifications

• Width (mm): 900
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 396.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 186
• Packed Width (mm): 945.0
• Packed Height (mm): 1225.0
• Packed Depth (mm): 945.0
• Shipping Cubic: 1.093956000m3
• Material: 304 Stainless Steel
• Undershelf: Yes (Suite Matching)
• Splash Back: Yes (165mm)
• No. of Shelves: 1
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Installation Type: Freestanding
• Control Type: Thermostat
• Mounting Type: Freestanding
• Fuel Type: Gas
• Griddle Plate Thickness (mm): 20
• Griddle Surface: Smooth Mild Steel
• Cooking Surface Area (mm): 900 x 480
• Number of Burners: 3
• Power Rating: 304 Stainless Steel
• Power Supply: N/A (Gas)
• Voltage/Phase: N/A (Gas)
