Blue Seal GP513-CB Evolution Series 450mm Gas Griddle with Cabinet Base

The Blue Seal GP513-CB is a heavy-duty 450mm gas griddle from the Evolution Series, mounted on a fully enclosed cabinet base for integrated underbench storage. Powered by a 40 MJ/hr (11.1–11.5 kW) thermostatic burner system, it delivers rapid heat-up and consistent heat distribution across a 442 mm x 530 mm cooking surface, making it well suited to cafés, restaurants, takeaway shops, hotels, and high-volume hospitality kitchens handling breakfasts, burgers, steaks, eggs, bacon, seafood, and sandwiches.

Built around a 20 mm thick machined griddle plate, the GP513-CB offers outstanding thermal retention and recovery to maintain cooking performance during peak service. The unit is available in natural gas or LPG configurations and in smooth mirror or ribbed plate finishes to suit different cooking styles. Fully modular construction allows it to be paired with other Evolution Series equipment for a matched suite, while practical design details including top-weld sealed plates, a stainless steel grease drawer, piezo ignition, and flame failure protection keep the unit safe, hygienic, and straightforward to service.

Key Benefits

• Even, consistent heat across the full cooking surface speeds up service and reduces the risk of hot spots during busy periods.
• 20 mm thick griddle plate retains and recovers heat quickly, maintaining cooking temperatures even when loading the surface with multiple items at once.
• Precise 90–300°C thermostatic control gives operators reliable temperature management across a wide range of menu items.
• Top-weld sealed plate design and a removable stainless steel grease drawer make cleaning fast and thorough, reducing downtime between services.
• Full pilot and flame failure protection combined with push-button piezo ignition improves operator safety and simplifies start-up.
• Enclosed cabinet base provides valuable, accessible storage for cookware, trays, and kitchen essentials, improving kitchen organisation.
• Adjustable front feet and two rear rollers make levelling and repositioning the unit straightforward during installation or cleaning.
• Fully modular design pairs seamlessly with other Evolution Series units to create a matched, professional cooking suite.
• Available in natural gas or LPG, with mirror chrome or ribbed plate options, allowing the unit to be specified to suit kitchen infrastructure and menu requirements.

Key Features

• 450 mm wide gas griddle mounted on a fully enclosed cabinet base
• 40 MJ/hr (11.1–11.5 kW) thermostatic gas burner system
• 20 mm thick machined griddle plate for superior heat retention and recovery
• Thermostatic temperature control range: 90°C to 300°C
• Cooking surface area: 442 mm x 530 mm
• Choice of smooth mirror-chromed or ribbed machine-finished mild steel plate
• Top-weld sealed plate construction for hygienic, easy cleaning
• Stainless steel grease drawer for simple grease collection and removal
• Full pilot and flame failure protection with push-button piezo ignition
• 2.5 mm thick 304 stainless steel splash guards on sides and rear
• Double-skin 0.9 mm 304 stainless steel interior and exterior on cabinet base
• GN 1/1 four-position racking inside the cabinet base
• 63 mm diameter heavy-duty 1.2 mm 304 stainless steel legs
• Two adjustable feet at the front and two rollers at the rear for levelling and mobility
• Large, heat-resistant reinforced control knob for easy, safe operation
• Fully modular design compatible with Evolution Series suite for a matched finish
• Available in natural gas or LPG configurations
• Overall dimensions: 450 mm W x 812 mm D x 1085 mm H (including splashback)
• Packed weight: 130 kg

Specifications

• Width (mm): 300
• Depth (mm): 1085
• Height (mm): 812
• Weight (kg): 340.0
• Shipping Weight: 130
• Packed Width (mm): 870.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 495.0
• Shipping Cubic: 0.540466000m3
• Fuel Type: Gas
• Cooking Surface Area (mm): 442mm x 530mm
