Blue Seal GP516-RB Evolution Series 900mm Gas Griddle with Refrigerated Base

The Blue Seal GP516-RB Evolution Series combines a high-output 900mm gas griddle with an integrated refrigerated base, delivering a complete cooking and cold storage solution in a single 900mm footprint. Built in New Zealand from 304 stainless steel, the unit features an 80MJ/hr thermostatic burner system with two independent 90–300°C thermostat controls, a 20mm thick smooth mild steel griddle plate with top weld sealed construction, and a welded hob surround with a 1.5mm 304 stainless steel bull nose for robust, easy-clean performance during demanding service periods.

The refrigerated base maintains a temperature range of -2°C to +8°C and is tropical climate rated, keeping ingredients at safe holding temperatures directly beneath the cooking surface. Two GN 1/1 drawers with 100mm deep pan capacity provide organised, accessible ingredient storage, while the ventilated R134a refrigeration system with an anti-corrosion treated evaporator requires no condensate drain. The unit is available in Natural Gas or LPG configurations and accepts an optional ribbed or chrome mirror griddle plate for menu versatility.

Key Benefits

• Integrated refrigerated base keeps prep ingredients within arm's reach of the cooking surface, reducing transit time and improving service speed during peak periods.
• 80MJ/hr thermostatic burner output delivers rapid heat recovery across the full 892 x 530mm cooking surface, minimising downtime between batches.
• Two independent 90–300°C thermostat zones allow simultaneous cooking of different proteins or products at separate temperatures on a single unit.
• Tropical climate rated refrigeration (-2°C to +8°C) reliably maintains food safety temperatures even in hot and humid kitchen environments.
• No condensate drain required simplifies installation and reduces ongoing maintenance obligations.
• Push-button piezo ignition and heavy-duty reinforced control knobs allow quick, safe start-up and precise heat management without tools.
• Two rear rollers and two front adjustable feet make repositioning for cleaning or servicing straightforward, without requiring additional equipment.
• Stainless steel interior and exterior with an anti-corrosion treated evaporator ensure long service life in high-moisture commercial environments.
• Optional ribbed or chrome mirror griddle plate (additional charges apply) expands menu capability without replacing the unit.

Key Features

• 900mm wide gas griddle mounted on an integrated refrigerated base unit
• 80MJ/hr thermostatic burner system with six burners
• Two independent thermostat controls, each adjustable from 90°C to 300°C
• 20mm thick smooth mild steel griddle plate with top weld sealed construction
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Cooking surface area: 892 x 530mm
• Optional ribbed or chrome mirror griddle plate available (additional charges apply)
• Push-button piezo ignition for each burner zone
• Heavy-duty reinforced control knobs for precise heat adjustment
• Stainless steel grease drawer for straightforward grease collection and cleaning
• Refrigerated base temperature range: -2°C to +8°C, tropical climate rated
• Ventilated refrigeration system using R134a refrigerant
• Anti-corrosion treated evaporator; no condensate drain required
• Two GN 1/1 drawer configuration with 100mm deep pan capacity
• Digital thermostat and digital electronic display for refrigeration control
• Stainless steel exterior and interior throughout
• 63mm diameter heavy-duty 1.2mm 304 stainless steel legs
• Two adjustable feet at front for levelling; two rollers at rear for mobility
• 165mm splashback included (overall height including splashback: 1085mm; unit height: 915mm)
• Available in Natural Gas or LPG; R 3/4 (BSP) male gas connection
• Power supply: 220–240V, 50Hz, single phase, 1.8A; 3-pin 10A plug cordset fitted
• 304 stainless steel construction throughout
• Manufactured in New Zealand
• Easy clean, installation and service design

Specifications

• Width (mm): 900
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 396.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Shipping Weight: 200
• Packed Width (mm): 945.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 495.0
• Shipping Cubic: 0.587058000m3
• Material: 304 Stainless Steel
• Undershelf: Refrigerated Base
• Door Type: Drawer
• Splash Back: Yes (165mm)
• No. of Doors: 2
• Country of Origin: New Zealand
• Warranty (months): 12
• Capacity (Litres): 2
• Temperature Range: 0°C to 4°C
• Refrigeration Type: Ventilated | R134a
• Cooling Type: Ventilated | Tropical Rated
• Installation Type: Undercounter
• Control Type: Digital Thermostat
• Temperature Control: Thermostat | 90-300°C
• Display Type: Digital Electronic
• Fuel Type: Gas / Electric
• Griddle Plate Thickness (mm): 20
• Griddle Surface: Smooth Mild Steel (Ribbed or Chrome Optional)
• Cooking Surface Area (mm): 892 x 530
• Number of Burners: 6
• Power Rating: 1.8A|1P+N+E 3 pin 10A plug cordset fitted|220-240Vac|50Hz
• Power Supply: 220-240 Vac | 1P+N+E | 50Hz
• Voltage/Phase: 230V Single Phase
