Overview

Waldorf GPL8600E-B 800 Series 600mm Electric Griddle Low Back Bench Model

The Waldorf GPL8600E-B is a 600mm electric griddle from the 800 Series, designed as a bench-mount model for high-volume commercial kitchens. Powered by 7.2kW heating elements and fitted with a 20mm thick machined griddle plate across a single temperature control zone, it delivers consistent, even heat for cooking breakfasts, burgers, seafood and more throughout a busy service.

Constructed from 304 stainless steel throughout, this griddle features top weld-sealed plates with overlapping front and rear edges for effortless cleaning, a stainless steel grease drawer, and a welded hob surround with a bull nose finish. Four heavy-duty adjustable bench legs with two additional rollers make positioning and relocation straightforward, while optional ribbed or chrome mirror plate configurations allow the unit to be tailored to specific menu requirements.

Key Benefits

• The 20mm thick machined griddle plate retains and distributes heat evenly across the entire cooking surface, reducing hot spots and improving food consistency.
• A single temperature control zone with a 50–300°C thermostat gives operators precise, responsive control over cooking temperatures for a wide variety of products.
• Top weld-sealed plates with overlapping edges at the front and rear minimise food and grease trapping, significantly reducing cleaning time between services.
• The stainless steel grease drawer collects drippings efficiently and slides out for quick emptying, supporting hygiene and reducing downtime.
• Adjustable bench legs with a height range of 80–105mm, combined with two additional rollers, allow the unit to be levelled precisely and repositioned with minimal effort.
• Large, heat-resistant reinforced control knobs with easy-view settings and separate power and heating indicator lights help kitchen staff monitor and adjust the griddle safely and accurately.
• Optional ribbed plate sections or mirror-finish hard chrome plates mean the same unit can be configured for different cooking styles, from searing proteins to delicate fish or pancakes.
• Bench-model format suits kitchens where under-counter space is needed elsewhere, and the compact 600mm width fits neatly into tight cooking lines.

Key Features

• 600mm wide bench-mount electric griddle, 800 Series
• 7.2kW heating elements; single-phase 230–240V AC, 30A, 50/60Hz supply
• 20mm thick machined griddle plate as standard
• Single temperature control zone; thermostatic control range 50–300°C
• Top weld-sealed griddle plates with overlapping finish at front and rear for easy cleaning
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• 2.5mm thick 304 stainless steel splash guards to sides and rear
• 2.0mm thick grease channel
• Splashback and side panels in 1.2mm 304 stainless steel
• Front panels in 0.9mm 304 stainless steel
• Stainless steel grease drawer
• Large heat-resistant reinforced control knob with easy-view settings
• Indicator lights for power and heating status
• Four 63mm diameter heavy-duty 1.2mm 304 stainless steel bench legs with adjustable feet
• Adjustable leg height range 80–105mm
• Two additional rollers supplied for repositioning
• Optional ribbed plate sections available
• Optional mirror-finish hard chrome plates available
• Overall dimensions: 600mm W x 805mm D x 372mm H
• Packed weight: 170kg
• Manufactured in New Zealand
• 24-month warranty

Specifications

• Width (mm): 600
• Depth (mm): 805
• Height (mm): 370
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG / Natural Gas
• Gas Connection: 3/4" BSP Male
• Burner Output (MJ/h): 53
• Material: 304 Stainless Steel
• Undershelf: No
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 24
• Temperature Range: 100-290°C
• Fuel Type: Electric
• Number of Burners: 2
• Griddle Surface: Smooth
• Power Rating: 1P+N+E|230-240Vac|30A|50/60Hz|7.2kW
• Temperature Control: Thermostatic
