Blue Seal IN512R3-CB Evolution Series 450mm Double Zone Induction Cooktop – Cabinet Base

The Blue Seal IN512R3-CB is a 450mm freestanding electric induction cooktop from the Evolution Series, built in New Zealand from 304 stainless steel and designed for the demands of busy commercial kitchens. It features two 3.5kW round induction zones set into a 6mm thick ceramic glass cooking surface, mounted on a sturdy cabinet base with a single hinged door and a 165mm splashback for a complete, self-contained cooking station.

Powered by a 400–415V three-phase supply delivering 7.0kW total output, the unit uses forced air cooling and digital induction controls with infinitely variable power adjustment for each zone. Automatic pan detection shuts off each induction zone the moment cookware is removed, conserving energy and improving safety. Stainless steel legs with two adjustable feet at the front and two rear rollers make positioning and levelling straightforward, while the smooth ceramic glass surface keeps cleaning quick and simple.

Key Benefits

• Rapid, responsive induction heating reduces heat-up times and allows immediate power adjustments, supporting a faster kitchen workflow.
• Automatic pan detection turns off each zone when cookware is lifted, preventing wasted energy and reducing the risk of accidental burns.
• Infinitely variable power control per zone gives chefs precise, consistent heat management across a wide range of cooking tasks.
• The cool-to-the-touch ceramic glass surface around active zones creates a safer working environment and reduces the ambient heat load in the kitchen.
• Integrated cabinet base with a hinged door provides dedicated undercounter storage, keeping the workstation organised without requiring additional cabinetry.
• Two adjustable front feet and two rear rollers allow easy levelling on uneven floors and straightforward repositioning during cleaning or kitchen reconfiguration.
• Indicator lights for heating status, pan detection and error conditions give instant visual feedback, helping staff identify and respond to issues quickly.
• Heavy-duty 304 stainless steel construction and a 1.2mm stainless steel splashback deliver long-term durability and resistance to the rigours of commercial use.
• Designed for easy installation, cleaning and servicing, minimising downtime and reducing the cost of routine maintenance.

Key Features

• Double cooking zone electric induction cooktop mounted on an integrated cabinet base
• 2 x 3.5kW round induction heating zones, 7.0kW total power output
• 2 x 270mm diameter round induction zones accommodating a range of round-base cookware
• 6mm thick ceramic glass cooking surface, 900 x 480mm total cooking surface area
• Automatic pan detection switches each induction zone off immediately when cookware is removed
• Large control knob per zone with infinitely variable power adjustment for precise heat control
• Indicator lights for heating-on status, pan detection and error conditions
• Digital induction control system with variable power control
• Forced air (fan) cooling system
• 165mm rear splashback, 1.2mm stainless steel construction
• Single hinged door on the cabinet base
• 304 stainless steel body in a stainless steel finish
• Stainless steel legs with 2 adjustable feet at the front and 2 rollers at the rear for easy levelling and movement
• Freestanding installation, 450mm wide footprint
• Powered by 400–415V, 3P+E, 50/60Hz, 10A per phase
• Heavy-duty construction engineered for commercial kitchen environments
• Manufactured in New Zealand
• Racking kit not included

Specifications

• Width (mm): 450
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 340.0
• Colour: Stainless Steel
• Material: 304 Stainless Steel
• Undershelf: Cabinet Base
• Door Type: Hinged
• Splash Back: Yes (165mm)
• No. of Doors: 1
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Cooling Type: Forced Air | Fan Cooled
• Installation Type: Freestanding
• Control Type: Digital Induction Control
• Temperature Control: Variable Power Control
• Mounting Type: Freestanding
• Fuel Type: Electric
• Griddle Surface: 6mm Ceramic Glass
• Cooking Surface Area (mm): 900 x 480
• Number of Burners: 2
• Power Rating: 3P+E 10A / phase|400-415V|50/60Hz|7.0kW
• Power Supply: 400-415 Vac | 3P+E | 50/60 Hz
• Voltage/Phase: 400-415V 3P+E
