Blue Seal IN512R5-CB Evolution Series 450mm Induction Cooktop on Cabinet Base

The Blue Seal IN512R5-CB is a freestanding double-zone induction cooktop from the Evolution Series, built on a heavy-duty cabinet base and designed for the rigorous demands of commercial kitchens. Constructed in New Zealand from 304 stainless steel, it delivers two 5kW round induction zones across a 6mm ceramic glass cooking surface, with a combined output of 10kW on a three-phase power supply.

Engineered for efficiency and operator convenience, the IN512R5-CB features automatic pan detection that cuts power to each zone the moment a pan is removed, conserving energy and improving safety. Large control knobs with infinitely variable power settings give chefs precise, responsive heat management, while the smooth ceramic glass surface, integrated splashback, and forced-air cooling system make this unit practical for high-volume service.

Key Benefits

• Instant, responsive induction heat reaches cooking temperature faster than gas or radiant elements, reducing wait times during service.
• Automatic pan detection switches off each induction zone immediately when a pan is lifted, saving energy and preventing accidental burns on the cooking surface.
• Infinitely variable power control per zone allows precise temperature management, supporting consistent cooking outcomes across different menu items.
• The cooler, smooth ceramic glass surface reduces ambient kitchen heat and minimises burn risk compared to traditional open-flame or radiant cooktops.
• Forced-air fan cooling actively manages internal component temperatures, supporting reliability and longevity in continuous commercial use.
• The integrated cabinet base provides enclosed undercounter storage and a stable, self-contained footprint without requiring separate cabinetry.
• Stainless steel legs with two adjustable front feet and two rear rollers make levelling straightforward and allow the unit to be repositioned with minimal effort.
• The 165mm stainless steel splashback protects the wall behind the unit and simplifies post-service cleaning.
• Easy-clean ceramic glass surface, accessible construction and straightforward installation reduce both daily maintenance time and total cost of ownership.

Key Features

• Two 5kW round induction heating zones, delivering a combined 10kW total output.
• Two 270mm diameter round induction zones positioned on a 6mm thick ceramic glass cooking surface.
• Automatic pan detection on each zone: induction switches off immediately when a pan is removed.
• Large, easy-to-use control knob per zone with infinitely variable power adjustment.
• Indicator lights for heating-on status, pan detection confirmation and error notification.
• Forced-air (fan-cooled) cooling system for continuous-duty thermal management.
• Digital induction control with variable power control for each zone.
• Power supply: 10kW, 400-415V, 3P+E, 14A per phase, 50/60Hz.
• 304 stainless steel construction throughout.
• 1.2mm stainless steel splashback, 165mm high.
• Heavy-duty cabinet base with a single hinged door for enclosed underbench storage.
• Stainless steel legs with two adjustable feet at the front and two rollers at the rear for easy levelling and repositioning.
• Freestanding installation type.
• Overall dimensions: 450mm wide x 812mm deep x 1085mm high.
• Country of manufacture: New Zealand.
• Racking kit not included.

Specifications

• Width (mm): 450
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 340.0
• Colour: Stainless Steel
• Material: 304 Stainless Steel
• Undershelf: Cabinet Base
• Door Type: Hinged
• Splash Back: Yes (165mm)
• No. of Doors: 1
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Gas
• Cooling Type: Forced Air | Fan Cooled
• Installation Type: Freestanding
• Control Type: Digital Induction Control
• Temperature Control: Variable Power Control
• Mounting Type: Freestanding
• Fuel Type: Electric
• Griddle Surface: 6mm Ceramic Glass
• Cooking Surface Area (mm): 900 x 480
• Number of Burners: 2
• Power Rating: 10.0kW|3P+E 14A / phase|400-415V|50/60Hz
• Power Supply: 400-415 Vac | 3P+E | 50/60 Hz
• Voltage/Phase: 400-415V 3P+E
