Scotsman NUH 227 AS OX 98kg XSafe Self Contained Dice Ice Maker

The Scotsman NUH 227 AS OX is a self-contained dice ice maker delivering up to 98kg of ice per day, designed for busy commercial kitchens, bars, and hospitality venues where consistent, high-quality ice production is essential. With a built-in 37kg storage bin, front-to-front airflow and a compact footprint of 650mm wide, it fits neatly into tight spaces without sacrificing output capacity.

Built around Scotsman's vertical evaporator spray-system technology, the NUH 227 AS OX produces small 6g half-dice cubes measuring 10mm x 22mm x 28mm that are pure, clear, and transparent. Agion antimicrobial technology and the XSafe Natural Sanitation System work together to inhibit microbial growth and prevent odours, ensuring every batch of ice meets the highest hygiene standards. The unit operates on R290 EcoX hydrocarbon refrigerant gas and is rated for ambient temperatures up to 40°C.

Key Benefits

• High daily output of up to 98kg keeps pace with demand during peak service periods, reducing the risk of running short on ice.
• Integrated 37kg storage bin means ice is always on hand without the need for a separate storage unit, saving space and cost.
• Front in-and-out airflow allows the machine to be installed in confined or built-in spaces where side or rear clearance is limited.
• Agion Technology and the XSafe Natural Sanitation System continuously suppress microbial growth and odours, supporting food safety and producing consistently clean, clear ice.
• One-touch cleaning cycle significantly reduces the time and labour required for routine maintenance, keeping the unit in optimal condition with minimal effort.
• Ergonomic sliding disappearing door provides easy, comfortable access to the ice storage bin during busy service without obstructing the workspace.
• External indicator lights provide at-a-glance visibility of operational status and maintenance alerts, allowing staff to respond quickly to any issues.
• Easy-access front condenser air filter simplifies routine cleaning and helps maintain efficiency without the need for tools or specialist knowledge.
• R290 EcoX hydrocarbon refrigerant is a low global-warming-potential option, supporting venues with environmental sustainability commitments.

Key Features

• Up to 98kg daily ice production capacity
• Built-in 37kg ice storage bin
• Half-dice cube dimensions: 10mm (W) x 22mm (D) x 28mm (H), approximately 6g per cube
• Air cooled operation, rated for maximum ambient temperature of 40°C
• R290 EcoX hydrocarbon refrigerant gas
• Agion antimicrobial technology inhibits microbe growth and prevents odour development for pure, clear, transparent ice
• XSafe Natural Sanitation System for ongoing hygiene protection
• Vertical evaporator spray-system ice-making technology
• Front in-and-out airflow design suited to installation in tight or enclosed spaces
• Ergonomic sliding disappearing door for easy ice access
• One-touch cleaning function for fast, labour-saving maintenance
• Easy-access front condenser air filter for straightforward cleaning
• Durable stainless steel exterior construction
• External indicator lights display operational status and maintenance alerts
• Electrical: 230-240V, 1P+N+E, 50Hz, 480W, 10A cordset supplied
• Dimensions: 650mm (W) x 690mm (D) x 870mm (H)
• Packed weight: 77.5kg
• Includes removable air filter, ice scoop, and water and drain hose
• Optional leg kit available (SC8700000200, compatible with NU 100, NU 150, and NU 220 models)
• Water filter cartridge replacement every 6 months and periodic de-scaling of the evaporator plate recommended to maintain ice quality and machine performance
• Self-contained installation type

Specifications

• Width (mm): 10
• Depth (mm): 22
• Height (mm): 28
• Weight (kg): 340.0
• Colour: Stainless Steel
• Shipping Weight: 77.5
• Packed Width (mm): 651.0
• Packed Height (mm): 870.0
• Packed Depth (mm): 690.0
• Shipping Cubic: 0.390795000m3
• Material: Stainless Steel
• Country of Origin: Stainless Steel
• Warranty (months): Italy/USA
• Capacity (Litres): 30
• Ice Production: 100
• Ice Storage: 30
• Refrigeration Type: Air Cooled
• Cooling Type: Air Cooled
• Ice Type: Dice Cube
• Max Ambient Temp (°C): 40
• Refrigerant: R290
• Ice Size: Half Dice
• Installation Type: Self-Contained
• Voltage/Phase: 230V 50Hz
