Overview

Waldorf RN8610EC 800 Series 900mm Electric Range Convection Oven

The Waldorf RN8610EC is a 900mm wide commercial electric range from the 800 Series, combining a six-element radiant cooktop with a full-size GN 2/1 electric convection oven in a single, robust unit. Manufactured in New Zealand from 304 stainless steel with a galvanised steel chassis, it is engineered for the sustained demands of restaurants, hotels, cafes, catering operations and high-volume hospitality kitchens.

The cooktop delivers six 2.4kW open radiant elements with individual six-position temperature controls including a simmer setting, while the fan-forced convection oven distributes heat uniformly throughout the cavity to support roasting, baking and finishing. Its modular 800 Series design integrates seamlessly with other Waldorf equipment, making it a practical centrepiece for complete commercial kitchen fit-outs.

Key Benefits

• Fan-forced convection circulation reduces cooking times and allows lower operating temperatures, improving throughput and energy efficiency during peak service.
• Six independent radiant elements with simmer settings give chefs precise, flexible heat management across boiling, sautéing and holding tasks simultaneously.
• GN 2/1 oven capacity with four-position racking accommodates large batch loads, supporting high-volume baking and roasting without multiple cooking cycles.
• Vitreous enamel oven liner and element module spill trays resist grease build-up and wipe down quickly, reducing cleaning time between services.
• Adjustable feet and two rear rollers make levelling and repositioning straightforward, simplifying installation and routine service access.
• Welded hob construction with heavy-duty reinforced control knobs and a drop-down door fitted with a robust spring hinge mechanism provide long-term durability under constant commercial use.
• Modular 800 Series compatibility allows the unit to be paired with other Waldorf cooking equipment, enabling flexible and scalable kitchen configurations.
• Optional hot plate elements, featuring a machine-finished 8mm steel cooking surface, extend cooktop versatility for griddle-style cooking without requiring a separate appliance.

Key Features

• 900mm wide 800 Series modular electric range with integrated convection oven
• Six 2.4kW open radiant elements mounted in heavy-duty welded element frames
• Individual six-position temperature controls with simmer setting on each element
• Vitreous enamelled element modules and hob spill trays for easy cleaning
• Optional hot plate elements constructed from 8mm machine-finished steel plate
• GN 2/1 convection oven with four-position racking
• Two chrome wire oven racks supplied as standard
• Heavy-duty easy-remove chrome wire rack supports
• 6.5kW oven heating elements
• 100W heavy-duty circulation fan motor with 200mm diameter fan
• Cast iron even-heat oven sole plate for consistent base temperature
• Fully welded oven liner with vitreous enamel coating
• Thermostatic oven temperature control
• Welded frame drop-down oven door incorporating a heavy-duty spring hinge assembly
• Outer oven door panel in 0.9mm 304 stainless steel
• Press-formed vitreous enamelled inner door panel in 1.0mm steel
• High-density fibreglass door insulation
• Temperature-resistant stainless steel door handle mounted on cast metal brackets
• Galvanised steel chassis with welded hob construction
• 1.5mm 304 stainless steel bull nose on welded hob
• Splashback and hob sides in 1.2mm 304 stainless steel
• Oven sides and front panels formed from 0.9mm 304 stainless steel, with front cladding in 1.2mm 304 stainless steel
• Heavy-duty 1.2mm 304 stainless steel legs, 63mm diameter and 150mm tall, with adjustable feet
• Two additional rear rollers for repositioning
• Aluminised steel internal cooktop construction
• Integrated splashback
• Heavy-duty reinforced control knobs
• Manufactured in New Zealand
• 24-month warranty
• 800 Series modular design for integration with other Waldorf cooking suites

Specifications

• Width (mm): 900
• Depth (mm): 805
• Height (mm): 1130
• Weight (kg): 640.0
• Colour: Stainless Steel
• Gas Type: LPG / Natural Gas
• Shipping Weight: 263
• Packed Width (mm): 945.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 1.031798000m3
• Material: 304 Stainless Steel
• Undershelf: No
• Door Type: Drop Down
• No. of Shelves: 2
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 24
• Temperature Range: Variable (Cooktop), 150-300°C (Oven)
• Fuel Type: Electric
• Number of Burners: 6
• Power Rating: 21.0 kW|3P+N+E|400-415Vac|50/60Hz
• Power Supply: 415V 3 Phase
• Voltage (V): 415
• Voltage/Phase: 21.0kW, 400-415Vac, 50/60hz, 3P+N+E, 30A/phase
• Temperature Control: Thermostatic
• Display Type: Analog
