Overview

Waldorf RN8619GEC 800 Series 900mm Gas Range Electric Convection Oven

The Waldorf RN8619GEC is a heavy-duty commercial range combining a 900mm gas griddle cooktop with a 2/1 GN electric convection oven below, purpose-built for high-volume commercial kitchens. The griddle section is powered by three 20MJ/hr burners delivering a total gas rating of 60MJ, while the convection oven draws 6.5kW (single phase) or 6.6kW (three phase), giving operators flexibility in both cooking power and electrical installation.

Constructed with a heavy-duty stainless steel finish throughout, this unit is engineered for ease of cleaning, servicing and long-term durability. Features such as removable cast iron burners, vitreous enamel pot stands and a welded vitreous enamel oven lining make daily maintenance straightforward, while heavy-duty convection motors and circulation fans promote even heat distribution and reduce cooking times across the full oven capacity.

Key Benefits

• Fan-forced convection circulation enables faster cooking at lower temperatures, improving energy efficiency and throughput during busy service periods.
• Full 900mm griddle width across three burners provides ample simultaneous cooking surface for high-volume breakfast, lunch and dinner service.
• 2/1 GN oven capacity accommodates large gastronorm trays, making batch cooking and roasting practical for catering-scale operations.
• Flame failure protection on all burners automatically cuts gas supply if a flame extinguishes, reducing safety risks in busy kitchen environments.
• Vitreous enamel oven lining and pot stands resist staining and are easy to wipe clean, minimising downtime between services.
• Adjustable feet and two additional rollers allow precise levelling on uneven floors and straightforward repositioning during kitchen reconfiguration or cleaning.
• Heavy-duty reinforced control knobs and a cool touch stainless steel door handle withstand repeated daily use and reduce burn risk for operators.
• Flexible electrical supply options (single phase or three phase) simplify installation across a variety of commercial kitchen configurations.

Key Features

• 900mm gas griddle cooktop with three 20MJ/hr burners; total gas rating 60MJ
• 2/1 GN capacity electric convection oven with heavy-duty motor and circulation fan
• Electrical supply options: 6.5kW, 1P+N+E, 27A (single phase) or 6.6kW, 3P+N+E, 10A (three phase)
• Heavy-duty stainless steel construction and finish throughout
• Flame failure protection on all burners
• Removable heavy-duty cast iron burners for easy cleaning and servicing
• Vitreous enamel pot stands, removable for maintenance
• Welded oven lining finished in vitreous enamel for durability and easy cleaning
• Drop-down oven door with welded frame construction
• Cool touch stainless steel oven door handle
• Heavy-duty reinforced control knobs
• Adjustable feet with two additional rollers for levelling and mobility
• Designed for easy cleaning, installation and servicing
• Note: product images may show model RN8610GEC

Specifications

• Width (mm): 900
• Depth (mm): 805
• Height (mm): 1130
• Weight (kg): 340.0
• Shipping Weight: 274
• Packed Width (mm): 945.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 1.031798000m3
