Overview

Waldorf RN8813GC 800 Series 1200mm Gas Range Convection Oven

The Waldorf RN8813GC is a 1200mm wide commercial gas range from the 800 Series, combining a six-burner cooktop with a 300mm griddle section over a 2/1 GN gas convection oven. Designed for high-volume commercial kitchens, the unit delivers substantial cooking power across both the cooktop and the fan-forced oven, with six 28MJ/hr open burners and a 20MJ/hr dedicated griddle burner providing a combined gas rating of 218MJ. A storage cabinet is included on the right-hand side, making this a self-contained cooking station suited to busy service environments.

Construction throughout emphasises durability and ease of maintenance. The cooktop features removable heavy-duty cast iron burners on vitreous enamel pot stands, and the oven cavity is welded and lined with vitreous enamel for straightforward cleaning. Heavy-duty motors and circulation fans within the convection oven promote even heat distribution, allowing food to be cooked at lower temperatures in reduced timeframes. Flame failure protection is fitted to all burners for added operational safety, and the unit is engineered with accessibility in mind for installation, daily cleaning and routine servicing.

Key Benefits

• Fan-forced convection oven circulates heat evenly, reducing cooking times and allowing lower operating temperatures to save energy and protect food quality.
• Six high-output 28MJ/hr open burners across the cooktop deliver rapid, controllable heat suited to simultaneous multi-pot cooking during peak service.
• Integrated 300mm griddle with a dedicated 20MJ/hr burner provides a ready surface for proteins, bread and breakfast items without needing a separate appliance.
• 2/1 GN oven capacity accommodates large gastronorm trays, supporting high-volume batch cooking for banqueting and catering operations.
• Flame failure protection on every burner automatically cuts gas flow if a flame extinguishes, improving kitchen safety and compliance.
• Vitreous enamel oven lining and pot stands resist staining and are easy to wipe down, reducing cleaning time between services.
• Adjustable feet and two additional rollers simplify positioning and levelling on uneven kitchen floors, and allow the unit to be moved for behind-the-range cleaning.
• Cool-touch stainless steel door handle and heavy-duty reinforced control knobs stand up to continuous daily use while keeping operating staff comfortable and safe.
• Available in both natural gas and LPG configurations, offering flexibility to suit different site utility connections.

Key Features

• 1200mm wide 800 Series modular gas range configuration
• Six-burner cooktop with integrated 300mm griddle section positioned on the right-hand side as standard
• 6 x 28MJ/hr patented open cooktop burners
• 1 x 20MJ/hr dedicated griddle burner
• Total gas rating: 218MJ
• 2/1 GN gas convection oven with heavy-duty motor and circulation fan
• Cast iron sole plates inside the oven for even heat distribution
• Welded oven cavity lined with vitreous enamel for durability and easy cleaning
• Drop-down oven door with welded frame construction
• Cool-touch stainless steel door handle
• Flame failure protection fitted to all burners
• Removable heavy-duty cast iron burners for straightforward cleaning and servicing
• Vitreous enamel pot stands
• Heavy-duty reinforced control knobs
• Heavy-duty stainless steel exterior finish throughout
• Storage cabinet on the right-hand side
• Adjustable feet plus two additional rollers for positioning and levelling
• Electrical requirement: 0.13kW, 10A with cordset fitted
• Available in natural gas and LPG variants
• Designed for easy cleaning, installation and servicing

Specifications

• Width (mm): 1200
• Depth (mm): 805
• Height (mm): 1130
• Weight (kg): 355.0
• Shipping Weight: 345
• Packed Width (mm): 1245.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 1.359353000m3
