Overview

Waldorf RN8816GC 800 Series 1200mm Gas Range Convection Oven

The Waldorf RN8816GC is a heavy-duty 1200mm commercial gas range from the acclaimed 800 Series, combining four open burners, a 600mm gas griddle, and a 2/1 GN fan-forced gas convection oven into a single, high-output cooking suite. Designed for restaurants, cafes, hotels and high-volume institutional kitchens, it delivers versatile cooking performance across boiling, sautéing, grilling and batch baking from one compact footprint.

Built for the rigours of professional kitchen environments, the RN8816GC features a full stainless steel exterior with galvanised steel chassis, vitreous enamel oven lining, heavy-duty cast iron burners and reinforced controls throughout. A right-hand storage cabinet, adjustable feet and rear rollers make installation, daily operation and routine servicing straightforward, while its modular design integrates seamlessly with other Waldorf 800 Series equipment.

Key Benefits

• Four 28MJ/hr open burners deliver immediate, responsive heat for rapid boiling, sautéing and frying during peak service periods.
• The 600mm gas griddle powered by two 20MJ/hr burners provides consistent surface heat for grilling, searing and high-volume breakfast or protein cookery.
• Fan-forced gas convection oven promotes even heat circulation, reducing cooking times and supporting consistent results across multiple trays simultaneously.
• Thermostatic temperature control from 50°C to 320°C gives chefs precise control for everything from gentle warming to high-heat roasting and baking.
• Flame failure protection on all burners automatically cuts gas supply if a flame extinguishes, reducing the risk of gas build-up in a busy kitchen environment.
• Vitreous enamel oven lining and welded interior construction resist staining and are straightforward to wipe down, reducing cleaning time between services.
• Adjustable feet and two rear rollers simplify positioning during installation and allow the unit to be moved for thorough cleaning and maintenance access.
• Right-hand storage cabinet keeps essential cookware and utensils close at hand, improving workflow efficiency on the line.
• Modular 800 Series design allows the unit to be configured within a broader cooking suite, supporting flexible kitchen layouts and future expansion.

Key Features

• 1200mm wide 800 Series heavy-duty commercial gas range
• 4 x 28MJ/hr open gas burners for high-output cooktop performance
• 600mm gas griddle section positioned on the right-hand side as standard
• 2 x 20MJ/hr gas burners powering the griddle plate
• 2/1 GN fan-forced gas convection oven with thermostatic control from 50°C to 320°C
• Cast iron sole plate in oven for even heat distribution
• Heavy-duty cast iron burners with forged brass caps for maximum heat transfer and longevity
• Removable cast iron burners and vitreous enamel pot stands for easy cleaning
• Flame failure protection on all burners including griddle
• Welded vitreous enamel oven lining for durability and simple maintenance
• Drop-down oven door with welded frame construction
• Cool-touch stainless steel oven door handle
• Full stainless steel exterior with galvanised steel chassis
• Welded bull nose construction for structural integrity and seamless modular joining
• Heavy-duty reinforced control knobs for consistent, reliable operation under frequent use
• Right-hand storage cabinet included as standard
• Adjustable feet for levelling on uneven floors
• Two rear rollers for repositioning during installation and servicing
• Compatible with natural gas and LPG configurations
• Modular design for integration within Waldorf 800 Series cooking suites

Specifications

• Width (mm): 1200
• Depth (mm): 805
• Height (mm): 1130
• Weight (kg): 355.0
• Shipping Weight: 345
• Packed Width (mm): 1245.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 1.359353000m3
