Overview

Waldorf RNL8403E-B 800 Series 600mm Electric Cooktop – Low Back Bench Model

The Waldorf RNL8403E-B is a 600mm wide bench-mount electric cooktop from the heavy-duty 800 Series, combining two 2.4kW radiant elements with a 300mm griddle section powered by a 3.6kW element, with the griddle positioned on the right-hand side as standard. The unit is constructed throughout in 304 stainless steel, featuring a welded hob with a 1.5mm bull nose edge, 12mm mild steel griddle plates, and aluminised steel internal construction, making it well suited to high-volume commercial kitchen environments.

Designed with the operator in mind, the RNL8403E-B offers six temperature settings including a simmer position on each radiant element, a 50 to 320°C thermostat governing the griddle section, and dedicated power and heating status indicator lights on every element control. Four heavy-duty bench legs with adjustable feet covering a height range of 80 to 105mm provide installation flexibility, while hinge-up element and griddle sections, removable spill trays, and full front access make routine cleaning and servicing straightforward.

Key Benefits

• Versatile cooking surface combining radiant elements and a griddle within a compact 600mm footprint, reducing the number of separate appliances required on the line.
• Six temperature settings per radiant element, including a dedicated simmer position, give precise control across a wide range of menu items from delicate sauces to high-heat searing.
• A thermostat ranging from 50 to 320°C on the 300mm griddle section allows accurate temperature management for consistent results when cooking proteins, eggs or vegetables.
• Each element control features both a power indicator and a heating status indicator light, so staff can monitor cooking conditions at a glance and reduce the risk of leaving elements on unintentionally.
• Hinge-up element and griddle sections combined with fully removable, vitreous enamelled spill trays make end-of-service cleaning faster and more thorough.
• Full front access to all serviceable parts minimises downtime during maintenance and makes scheduled servicing quicker for technicians.
• Adjustable bench legs across an 80 to 105mm height range accommodate uneven floors and allow the unit to be levelled precisely during installation.
• An optional hot plate configuration using machine-finished 8mm steel plate elements provides an additional cooking mode to suit changing menu requirements.
• Heavy-duty reinforced control knobs with easy-view settings marked directly on the knob withstand the rigours of continuous commercial use and remain legible under busy kitchen conditions.

Key Features

• 2 x 2.4kW open radiant elements set in heavy-duty welded element frames
• 1 x 3.6kW griddle element powering a 300mm griddle section, positioned on the right-hand side as standard
• 12mm thick mild steel griddle plates with griddle splash guards fabricated from 2.5mm 304 stainless steel
• Six temperature settings per radiant element including a simmer setting, controlled via energy regulator
• Griddle section thermostat with a 50 to 320°C operating range
• Power and heating status indicator lights fitted to each individual element control
• Welded hob constructed from 1.5mm 304 stainless steel with bull nose edge
• Splashback and side panels in 1.2mm 304 stainless steel; front panels in 0.9mm 304 stainless steel
• Aluminised steel internal construction
• Fully removable vitreous enamelled spill trays covering both the element modules and hob area
• Hinge-up element and griddle sections for easy access
• All serviceable parts accessible from the front of the unit
• Large heat-resistant reinforced control knobs with easy-view settings marked on knob
• Four 63mm diameter bench legs in 1.2mm 304 stainless steel, with adjustable feet and a height range of 80 to 105mm
• Two additional rollers included for repositioning the unit
• Optional hot plate elements available, featuring a machine-finished 8mm steel plate surface
• Low back version bench model configuration
• Heavy-duty stainless steel external finish throughout

Specifications

• Width (mm): 600
• Depth (mm): 805
• Height (mm): 370
• Weight (kg): 340.0
