Waldorf RNL8406G-LS 800 Series 600mm Gas Griddle Cooktop – Low Back, Leg Stand

The Waldorf RNL8406G-LS is a commercial 600mm griddle cooktop from the 800 Series, positioned on a leg stand and driven by two 20MJ/hr griddle burners across a 600mm griddle surface. Constructed throughout from heavy-duty 304 stainless steel and manufactured in New Zealand, the unit is built to withstand the continuous demands of high-volume professional kitchen service.

The low back configuration suits flexible installation requirements, while adjustable feet and two additional rollers simplify positioning and repositioning within the kitchen. Flame failure protection is fitted across every burner, and the griddle surface, cast iron burner components, and smooth pot stand design all contribute to a unit that is straightforward to operate, clean, and maintain between services.

Key Benefits

• Flame failure protection across every burner acts as a critical safety measure during sustained high-volume cooking sessions.
• Two 20MJ/hr griddle burners distribute powerful, consistent heat over the full 600mm griddle surface, making the unit well suited to high-output breakfast, brunch, and grill service.
• Vitreous enamel pot stands incorporating extended finger supports enable cookware to glide smoothly from one cooking zone to the next, improving workflow and cutting down on handling time.
• Cast iron burner components are fully removable and the griddle surface is smooth, making daily cleaning and routine upkeep quick and efficient to minimise downtime.
• Heavy-duty reinforced control knobs are designed to endure constant commercial use, retaining precise heat adjustment capability over time.
• Adjustable feet allow the unit to be levelled on uneven floors, and the two additional rollers make it easy to shift the unit for cleaning behind equipment or rearranging the kitchen layout.
• The leg stand configuration provides open underbench access, promoting airflow and making the unit accessible for servicing.
• Manufactured in New Zealand from 304 stainless steel throughout, the cooktop is engineered for long-term durability in demanding commercial environments.

Key Features

• 600mm griddle cooktop mounted on a leg stand in low back configuration
• 2 x 20MJ/hr griddle burners
• Flame failure protection fitted to every burner
• Fully removable heavy-duty cast iron burner components
• Vitreous enamel pot stands with extended finger supports for effortless pan transfer between zones
• Smooth griddle surface
• Thermostatic temperature control
• Heavy-duty reinforced control knobs
• Heavy-duty 304 stainless steel construction throughout
• Adjustable feet for levelling on uneven floors
• 2 additional rollers for easy repositioning
• Compatible with LPG and natural gas connections
• Undershelf included
• Splashback included
• Designed for easy cleaning, installation, and servicing
• Manufactured in New Zealand

Specifications

• Width (mm): 600
• Depth (mm): 805
• Height (mm): 970
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG / Natural Gas
• Gas Connection: LPG|Natural Gas
• Burner Output (MJ/h): 53
• Material: 304 Stainless Steel
• Undershelf: Yes
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: 100-290°C
• Fuel Type: Gas
• Number of Burners: 2
• Griddle Surface: Smooth
• Power Rating: 14.7 kW
• Temperature Control: Thermostatic
