Waldorf RNL8413G 800 Series 600mm Gas Range Static Oven Low Back Version

The Waldorf RNL8413G is a 600mm wide commercial gas range from the renowned 800 Series, combining a two-burner cooktop with a 300mm smooth griddle and a 1/1 GN gas static oven in a low back configuration. Manufactured in New Zealand from 304 stainless steel, it delivers a total burner output of 56MJ/h across two patented 28MJ/h open burners and a 20MJ/h griddle burner, making it well suited to high-volume commercial kitchens requiring consistent, reliable performance.

The oven cavity is welded and lined with vitreous enamel for even heat retention and straightforward cleaning, while cast iron sole plates promote uniform heat distribution across the full 150-300°C thermostatically controlled range. Thoughtful design details including adjustable feet, two additional rollers, removable cast iron burners, and heavy-duty reinforced control knobs ensure the unit is easy to install, service, and maintain day after day.

Key Benefits

• Patented 28MJ/h open burners deliver enhanced cooking power for faster service during peak periods
• Vitreous enamel oven lining and cast iron sole plates provide even heat distribution for consistent baking and roasting results
• Flame failure protection on all burners improves kitchen safety by automatically cutting gas if a flame is extinguished
• Thermostatic oven control across 150-300°C allows precise temperature management for a wide variety of menu items
• Adjustable feet and two additional rollers make positioning and repositioning the unit straightforward during installation or kitchen reconfiguration
• Removable cast iron burners and vitreous enamel pot stands simplify routine cleaning and reduce downtime
• Cool touch stainless steel door handle and drop down door with welded frame allow safe, convenient oven access in a busy service environment
• Compact 600mm footprint with 1/1 GN oven capacity maximises cooking output without requiring excessive floor space

Key Features

• Two-burner cooktop range with integrated 300mm smooth griddle positioned on the right-hand side as standard
• 1/1 GN gas static oven with thermostatic temperature control from 150-300°C
• 2 x 28MJ/h patented open cooktop burners
• 1 x 20MJ/h griddle burner
• Total burner output of 56MJ/h (15.6kW)
• Flame failure protection on all burners
• Removable heavy-duty cast iron burners with vitreous enamel pot stands
• Oven cavity welded and lined with vitreous enamel for even heat and easy cleaning
• Cast iron sole plates for uniform heat distribution throughout the oven
• Drop down oven door with welded frame construction
• Cool touch stainless steel door handle
• Heavy-duty reinforced control knobs with analogue display
• 2 oven shelves included
• Adjustable feet with 2 additional rollers for easy positioning
• Low back (splashback) version
• Heavy-duty 304 stainless steel construction throughout
• Compatible with both natural gas and LPG; R 3/4 (BSP) male gas connection
• Manufactured in New Zealand
• No undershelf

Specifications

• Width (mm): 600
• Depth (mm): 805
• Height (mm): 970
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Burner Output (MJ/h): 56
• Material: 304 Stainless Steel
• Undershelf: No
• Door Type: Drop Down
• No. of Shelves: 2
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: Variable (Cooktop), 150-300°C (Oven)
• Fuel Type: Gas
• Number of Burners: 2
• Griddle Surface: Smooth
• Power Rating: 15.6 kW
• Temperature Control: Thermostatic
• Display Type: Analog
