Overview

Waldorf RNL8600E-LS 800 Series 900mm Electric Cooktop Low Back Version – Leg Stand

The Waldorf RNL8600E-LS is a 900mm wide, six-element electric cooktop from the 800 Series, mounted on a dedicated leg stand and designed for high-volume commercial kitchens. It features six 2.4kW open radiant elements set into heavy-duty welded element frames with vitreous enamelled element modules and hob spill trays, delivering a total output of 14.4kW across a 415V three-phase supply. The welded hob is constructed from 1.5mm 304 stainless steel with a bull-nose edge, while splashbacks and side panels use 1.2mm 304 stainless steel and front panels 0.9mm 304 stainless steel, ensuring a robust and professional finish throughout.

The matching leg stand is fully modular for a seamless suite configuration, featuring 63mm diameter heavy-duty 1.2mm 304 stainless steel legs with adjustable feet plus two additional rollers for easy repositioning. A framed undershelf with a 0.9mm 304 stainless steel finish provides practical storage, and the quick-assembly stand design requires no tools. Each element is controlled by a heat-resistant reinforced knob with easy-view settings, six temperature positions including a simmer setting, and individual power and heating indicator lights. All serviceable components are accessible from the front of the unit, and the removable vitreous enamelled spill trays along with hinge-up element sections make cleaning straightforward. Optional hot plate elements with machine-finished 8mm steel plate are available as an upgrade.

Key Benefits

• Six independent 2.4kW radiant elements with six-position controls including a simmer setting give precise heat management across every cooking zone simultaneously.
• Individual power and heating indicator lights for each element allow kitchen staff to monitor cooktop status at a glance, reducing energy waste and improving safety.
• Adjustable feet and two integrated rollers make levelling and repositioning the unit simple, minimising downtime during kitchen reconfiguration or cleaning.
• Front-access servicing for all components reduces maintenance time and keeps the unit operational with minimal disruption to kitchen workflow.
• Removable vitreous enamelled element modules and hob spill trays, combined with hinge-up element sections, simplify daily cleaning and help maintain hygiene standards.
• The fully modular leg stand connects directly to the cooktop and aligns with other 800 Series equipment, supporting a consistent suite layout in professional kitchen fit-outs.
• Heavy-duty 304 stainless steel construction throughout ensures long-term durability and corrosion resistance under the demands of continuous commercial use.
• Optional hot plate elements with machine-finished 8mm steel plate expand cooking versatility without requiring a separate appliance.

Key Features

• Six 2.4kW open radiant elements in heavy-duty welded element frames, totalling 14.4kW output
• Six temperature settings per element including a simmer position, controlled by heat-resistant reinforced knobs with easy-view markings
• Individual power and heating indicator lights for each element control
• Vitreous enamelled element modules and hob spill trays, removable for cleaning
• Hinge-up element sections providing full access for cleaning and servicing
• All serviceable components accessible from the front of the unit
• Welded hob constructed from 1.5mm 304 stainless steel with bull-nose edge
• Splashback and side panels in 1.2mm 304 stainless steel
• Front panels in 0.9mm 304 stainless steel
• Aluminised steel internal construction
• Low back (splashback) version suited to against-wall installation
• Leg stand with 63mm diameter heavy-duty 1.2mm 304 stainless steel legs and adjustable feet
• Two additional rollers on the leg stand for easy repositioning
• Framed undershelf with 0.9mm 304 stainless steel finish
• Quick-assembly modular stand design requiring no tools
• Fully modular construction for matched 800 Series suite configuration
• Optional hot plate elements with machine-finished 8mm steel plate
• Optional 12mm thick mild steel griddle plates with 2.5mm 304 stainless steel griddle splash guards
• Powered by 415V three-phase supply (3P+N+E, 400–415Vac, 50/60Hz)
• Manufactured in New Zealand
• 24-month warranty

Specifications

• Width (mm): 900
• Depth (mm): 805
• Height (mm): 970
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG / Natural Gas
• Material: 304 Stainless Steel
• Undershelf: Yes
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 24
• Temperature Range: Variable High-Low
• Fuel Type: Electric
• Number of Burners: 6
• Power Rating: 14.4 kW|20A/phase|3P+N+E|400-415Vac|50/60Hz
• Power Supply: 415V 3 Phase
• Voltage (V): 415
• Temperature Control: Variable High-Low
