Overview

Waldorf RNL8603G-B 800 Series 900mm Gas Cooktop with 300mm Griddle Low Back Bench Model

The Waldorf RNL8603G-B is a 900mm wide bench model gas cooktop from the Waldorf 800 Series, combining four open burners rated at 28MJ/hr each with a 300mm smooth griddle plate powered by a dedicated 20MJ/hr griddle burner. Manufactured in New Zealand from 304 stainless steel, it is engineered for the rigorous demands of busy commercial kitchens, delivering a total output of 112MJ/hr across all cooking zones.

Designed with operator practicality in mind, the cooktop features flame failure protection on every burner, removable heavy-duty cast iron burners, and vitreous enamel pot stands with extended finger supports that allow cookware to slide smoothly between burners. The low back configuration suits bench installations where a full splashback is not required, and the unit comes with adjustable feet plus two additional rollers to simplify positioning and service access.

Key Benefits

• High output open burners at 28MJ/hr each deliver rapid, responsive heat for demanding cooking tasks across all four cooking zones.
• Dedicated 300mm smooth griddle at 20MJ/hr with thermostatic control provides consistent surface temperatures between 100°C and 290°C, ideal for proteins, eggs and delicate items.
• Flame failure protection on all burners automatically cuts gas supply if a flame is extinguished, improving kitchen safety.
• Vitreous enamel pot stands with extended finger supports allow pots and pans to glide easily from burner to burner, reducing handling effort during service.
• Removable cast iron burners and enamel pot stands simplify routine cleaning and routine maintenance.
• Heavy-duty reinforced control knobs withstand the rigours of continuous commercial use and repeated adjustment.
• Adjustable feet combined with two additional rollers make levelling straightforward and allow the unit to be moved easily for thorough cleaning or servicing.
• Compatible with LPG or natural gas, providing flexible installation across a wide variety of commercial kitchen setups.
• 304 stainless steel construction resists corrosion and is easy to sanitise, supporting food safety compliance in professional environments.

Key Features

• Four open burners each rated at 28MJ/hr, totalling 112MJ/hr combined output
• 300mm smooth griddle plate positioned on the right-hand side as standard, powered by a dedicated 20MJ/hr griddle burner
• Thermostatic temperature control on the griddle with a range of 100°C to 290°C
• Flame failure protection fitted to all burners
• Removable heavy-duty cast iron burners for easy cleaning and replacement
• Vitreous enamel pot stands with extended finger supports enabling smooth pan transfer between burners
• Heavy-duty reinforced control knobs designed for repeated use in high-volume kitchens
• Adjustable feet for precise levelling on uneven floors
• Two additional rollers to aid repositioning and facilitate cleaning or servicing
• Low back version with splashback included; bench model configuration
• 304 stainless steel construction throughout
• Compatible with both LPG and natural gas
• Manufactured in New Zealand
• Total power rating of 31.1kW
• Packed weight 174kg; volume 0.55m³

Specifications

• Width (mm): 900
• Depth (mm): 805
• Height (mm): 370
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG / Natural Gas
• Gas Connection: LPG|Natural Gas
• Burner Output (MJ/h): 112
• Material: 304 Stainless Steel
• Undershelf: No
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: 100-290°C
• Fuel Type: Gas
• Number of Burners: 4
• Griddle Surface: Smooth
• Power Rating: 31.1 kW
• Temperature Control: Thermostatic
