Waldorf RNL8609E-B 800 Series 900mm Electric Cooktop Low Back Version – Bench Model

The Waldorf RNL8609E-B is a 900mm electric cooktop from the 800 Series, designed as a bench-mounted unit with a low back profile for commercial kitchen installations. It combines a 900mm griddle with three 3.6kW griddle elements and optional hot plate elements, offering flexible, high-output cooking across multiple zones suited to busy foodservice operations.

Constructed with heavy-duty 304 stainless steel throughout, the RNL8609E-B features a welded hob with bull nose edging, vitreous enamelled element modules and hob spill trays, and 12mm thick mild steel griddle plates. The bench model ships with four heavy-duty stainless steel legs with adjustable feet, allowing height adjustment from 80mm to 105mm, plus two additional rollers for easy repositioning.

Key Benefits

• Three independently controlled 3.6kW griddle elements deliver consistent, high-output heat across the full 900mm cooking surface, supporting simultaneous multi-product cooking during peak service.
• A 50–320°C thermostat per 300mm griddle section gives precise temperature control over each cooking zone, reducing the risk of over or undercooking.
• Six temperature settings plus a simmer setting provide versatile heat management for a wide range of menu items, from delicate proteins to high-heat searing.
• Hinge-up element and griddle sections combined with front-of-unit service access make routine maintenance and deep cleaning straightforward, minimising downtime.
• Removable vitreous enamelled element modules and hob spill trays simplify cleaning after service, keeping the unit hygienic with minimal effort.
• Adjustable bench legs (80–105mm height range) and two additional rollers allow the unit to be levelled precisely on uneven floors and relocated easily during kitchen reconfiguration.
• Optional hot plate elements with machine-finished 8mm steel plate expand the unit's cooking versatility without requiring a separate appliance.
• Indicator lights for power and heating on each element control provide at-a-glance confirmation of operating status, supporting safe and efficient kitchen workflow.

Key Features

• 900mm griddle bench model with three 3.6kW griddle elements
• Six temperature settings plus dedicated simmer setting
• 50–320°C thermostat control per 300mm griddle section
• 12mm thick mild steel griddle plates for even, retained heat
• 2.5mm 304 stainless steel griddle splash guards
• Welded hob constructed from 1.5mm 304 stainless steel with bull nose edge
• Splashback and side panels in 1.2mm 304 stainless steel
• Front panels in 0.9mm 304 stainless steel
• 2.4kW open radiant elements housed in heavy-duty welded element frames
• Vitreous enamelled element modules and hob spill trays – removable for cleaning
• Aluminised steel internal construction
• Large heat-resistant reinforced control knobs with easy-view settings
• Energy regulator controls for radiant and hot plate elements
• Indicator lights for power and heating status on each element
• Hinge-up element and griddle sections for access and cleaning
• All service access from the front of the unit
• Heavy-duty stainless steel external finish across all surfaces
• Four 63mm diameter heavy-duty 1.2mm 304 stainless steel bench legs with adjustable feet
• Adjustable foot height range 80–105mm
• Two additional rollers supplied for ease of movement
• Optional hot plate elements with machine-finished 8mm steel plate

Specifications

• Width (mm): 900
• Depth (mm): 805
• Height (mm): 370
• Weight (kg): 340.0
