Waldorf RNL8609G-B 800 Series 900mm Gas Cooktop Low Back Version – Bench Model

The Waldorf RNL8609G-B is a 900mm gas cooktop from the renowned 800 Series, configured as a low back bench model with a full-width griddle plate. Designed and built in New Zealand from 304 stainless steel, it features three 20MJ/hr griddle burners delivering a combined output of 60MJ/hr, making it well suited to high-volume commercial kitchens that demand consistent, controllable cooking performance across a large surface area.

Thermostatic temperature control across a range of 100–290°C gives operators precise management over the smooth griddle surface, while flame failure protection on all burners provides an essential safety safeguard. The unit accepts both natural gas and LPG connections and is engineered for straightforward cleaning, installation and servicing, reducing operational downtime in busy kitchen environments.

Key Benefits

• Full 900mm griddle surface provides generous cooking area for high-volume breakfast, grill or flat-top cooking during peak service periods.
• Thermostatic control across 100–290°C allows precise temperature management, reducing the risk of over or undercooking across different menu items.
• Flame failure protection on every burner automatically cuts gas supply if a flame extinguishes, improving kitchen safety without operator intervention.
• Dual fuel compatibility with both natural gas and LPG gives flexibility for installation across a variety of commercial premises and site configurations.
• Adjustable feet and two additional rollers make positioning and levelling straightforward, and allow the unit to be moved easily for cleaning or reconfiguration.
• Removable cast iron burners and vitreous enamel pot stands simplify routine cleaning and maintenance, minimising labour time between services.
• Heavy-duty reinforced control knobs withstand the rigours of constant daily use, reducing wear-related maintenance calls over the life of the unit.
• New Zealand manufacture in 304 stainless steel ensures corrosion resistance and a finish that meets the hygiene standards required in commercial food preparation areas.

Key Features

• 900mm full-width smooth griddle plate bench model configuration
• 3 x 20MJ/hr griddle burners, 60MJ/hr total output (22.2 kW)
• Thermostatic temperature control, range 100–290°C
• Flame failure protection on all burners
• Compatible with natural gas and LPG connections
• Removable heavy-duty cast iron burners
• Vitreous enamel pot stands with extended finger supports allowing easy pan movement across the surface
• Smooth griddle surface for easy cleaning and versatile cooking
• Heavy-duty reinforced control knobs for durability under constant use
• Adjustable feet and 2 additional rollers for levelling and mobility
• Low back splashback included
• Constructed from 304 stainless steel
• Heavy-duty stainless steel exterior finish
• No undershelf on this configuration
• Designed for easy cleaning, installation and servicing
• Manufactured in New Zealand
• 800 Series modular design allows integration with other Waldorf 800 Series cooking equipment

Specifications

• Width (mm): 900
• Depth (mm): 805
• Height (mm): 370
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG / Natural Gas
• Gas Connection: LPG|Natural Gas
• Burner Output (MJ/h): 80
• Material: 304 Stainless Steel
• Undershelf: No
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 12
• Temperature Range: 100-290°C
• Fuel Type: Gas
• Number of Burners: 3
• Griddle Surface: Smooth
• Power Rating: 22.2 kW
• Temperature Control: Thermostatic
