Overview

Waldorf RNL8806G-LS 800 Series 1200mm Gas Cooktop with 600mm Griddle Low Back – Leg Stand

The Waldorf RNL8806G-LS is a 1200mm wide commercial gas cooktop from the 800 Series, combining four open burners with a 600mm griddle plate on a heavy-duty leg stand. Each open burner delivers 28MJ/hr of responsive heat, while the integrated griddle runs on two dedicated 20MJ/hr burners, giving kitchen teams the flexibility to sear, sauté and griddle simultaneously on a single unit. Flame failure protection is fitted to all burners as standard, and the griddle is positioned on the right-hand side. Manufactured in New Zealand from 304 stainless steel, the unit is compatible with both natural gas and LPG.

Designed with busy commercial kitchens in mind, the RNL8806G-LS features removable cast iron burners, vitreous enamel pot stands with extended finger supports that allow cookware to slide smoothly from burner to burner, and heavy-duty reinforced control knobs built to withstand daily high-volume use. Adjustable feet and two additional rollers simplify positioning and levelling on site, while the straightforward layout supports easy cleaning, installation and servicing. The leg stand includes an undershelf for additional storage, and a low back splash guard is fitted as standard.

Key Benefits

• Four 28MJ/hr open burners deliver fast, responsive heat for high-volume cooking across multiple dishes at once
• Dedicated 600mm griddle with two 20MJ/hr burners expands cooking versatility without requiring a separate appliance
• Flame failure protection on every burner automatically cuts gas if a flame is extinguished, improving kitchen safety
• Vitreous enamel pot stands with extended finger supports allow cookware to slide easily between burners, reducing handling time and spill risk
• Removable cast iron burners and pot stands simplify deep cleaning and ongoing maintenance during busy service periods
• Adjustable feet and two integrated rollers make positioning and levelling straightforward, accommodating uneven kitchen floors
• Heavy-duty reinforced control knobs withstand the demands of continuous commercial use without premature wear
• Compatible with both natural gas and LPG, giving flexibility across different site configurations
• Undershelf and low back splash guard provide practical storage and keep surrounding surfaces cleaner during service

Key Features

• Four open burners each rated at 28MJ/hr, with a combined open-burner output of 112MJ/hr
• Integrated 600mm griddle plate powered by two dedicated 20MJ/hr burners, positioned on the right-hand side as standard
• Total power output of 31.1kW
• Flame failure protection fitted to all burners as standard
• Removable heavy-duty cast iron burners for straightforward cleaning and servicing
• Vitreous enamel pot stands with extended finger supports allowing smooth pan-to-pan transfer
• Heavy-duty reinforced control knobs rated for intensive daily use
• Thermostatic temperature control with a range of 100–290°C
• Smooth griddle surface
• Adjustable feet plus two additional rollers for easy manoeuvring and precise levelling
• Leg stand with undershelf for additional under-bench storage
• Low back splash guard included
• Constructed from 304 stainless steel with a heavy-duty stainless steel finish
• Gas connection: R 3/4 (BSP) male, compatible with natural gas and LPG
• Manufactured in New Zealand
• 24-month warranty

Specifications

• Width (mm): 1200
• Depth (mm): 805
• Height (mm): 970
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Burner Output (MJ/h): 112
• Material: 304 Stainless Steel
• Undershelf: Yes
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 24
• Temperature Range: 100-290°C
• Fuel Type: Gas
• Number of Burners: 4
• Griddle Surface: Smooth
• Power Rating: 31.1 kW
• Temperature Control: Thermostatic
