Waldorf RNL8813GC 800 Series 1200mm Gas Range Convection Oven Low Back Version

The Waldorf RNL8813GC is a heavy-duty 1200mm gas range from the acclaimed 800 Series, combining a six-burner cooktop with a 300mm griddle and a 2/1 GN gas convection oven in a single, low back configuration purpose-built for high-volume commercial kitchens. Six patented 28MJ/hr open burners deliver serious cooking power across the top, while the 20MJ/hr griddle burner handles flat-top cooking, and the fan-forced convection oven below ensures consistent, even heat distribution throughout every cook cycle.

Engineered for reliability and ease of use, the RNL8813GC features heavy-duty cast iron burners, vitreous enamel pot stands and a fully welded oven lining lined with vitreous enamel for straightforward cleaning and long service life. Cast iron sole plates promote even heat distribution within the oven, and heavy-duty motors with circulation fans reduce cooking times, allowing food to be cooked at lower temperatures. A storage cabinet on the right-hand side adds practical utility, and the unit is designed for straightforward installation, cleaning and servicing.

Key Benefits

• Fan-forced convection circulation reduces cooking times and allows lower operating temperatures, saving energy and improving throughput
• Six high-output 28MJ/hr open burners plus a 300mm griddle provide versatile, powerful cooktop performance to handle multiple simultaneous menu items
• 2/1 GN oven capacity supports large-batch cooking for high-volume service in restaurants, hotels, caterers and institutional kitchens
• Flame failure protection on every burner enhances kitchen safety and complies with commercial gas safety requirements
• Vitreous enamel oven lining and pot stands are straightforward to wipe down, reducing labour during end-of-service cleaning
• Cast iron sole plates deliver even heat distribution across the oven floor, improving cook consistency for baked and roasted items
• Adjustable feet plus two additional rollers allow precise levelling and easy repositioning during cleaning or kitchen reconfiguration
• Low back design suits kitchens with height restrictions or where integration into a suite of equipment is required

Key Features

• Six-burner cooktop range with integrated 300mm griddle
• 2/1 GN gas convection oven with heavy-duty motor and circulation fan
• 6 x 28MJ/hr open burners with removable heavy-duty cast iron construction
• 1 x 20MJ/hr dedicated griddle burner
• Flame failure protection fitted to all burners
• Griddle positioned on the right-hand side as standard
• Storage cabinet on the right-hand side
• Heavy-duty stainless steel exterior finish throughout
• Removable cast iron burners and vitreous enamel pot stands
• Welded oven lining finished with vitreous enamel for durability and easy cleaning
• Cast iron sole plates for even heat distribution across the oven floor
• Drop-down oven door with welded frame construction
• Cool touch stainless steel door handle
• Heavy-duty reinforced control knobs
• Adjustable feet with two additional rollers for levelling and mobility
• Low back version suited to space-restricted or suite installations
• Designed for easy cleaning, installation and servicing

Specifications

• Width (mm): 1200
• Depth (mm): 805
• Height (mm): 970
• Weight (kg): 345.0
