Turbofan EC40M7 Full Size 7 Tray Manual Electric Combi Oven

The Turbofan EC40M7 is a full-size electric combi oven offering three manual cooking modes — convection, steam, and combination — in a compact 777mm wide footprint suited to restaurants, cafés, bakeries, and catering operations. Powered by 12.5kW of heating and built with straightforward electro-mechanical controls, it delivers consistent, repeatable results across seven full-size 1/1 GN trays without complex programming or a steep learning curve.

Direct steam generation, auto-reversing fan direction, and a smooth rounded cooking chamber work together to ensure even heat and moisture distribution across every load. An externally connected hand shower with triple-action water filter, door-open rapid cool-down, and manual chamber venting make end-of-shift cleaning and turnaround fast and practical, while LED chamber lighting and a double-glazed thermo-reflective door give operators a clear view of product at all times.

Key Benefits

• Three cooking modes — convection, steam, and combi — let a single oven handle roasting, baking, steaming, and menu regeneration without additional equipment.
• Compact 777mm width fits into tight kitchen layouts while still delivering a full seven-tray capacity, maximising output per square metre of floor space.
• Automatic fan direction reversal promotes uniform temperature and humidity distribution, reducing hot spots and the need for manual tray rotation mid-cook.
• Simple electro-mechanical dials for mode, time, and temperature keep operation intuitive for all skill levels, minimising training time and operator error.
• East-west tray loading configuration improves ergonomic access during busy service, speeding up loading and unloading.
• Door-open rapid cool-down function accelerates chamber cooling between cooking cycles, supporting faster turnaround during high-volume service.
• Externally connected hand shower with triple-action water filter simplifies manual cleaning at the end of service without requiring the chamber to cool fully first.
• Stainless steel construction with perfectly smooth, rounded-edge chamber walls resists corrosion and makes thorough sanitation straightforward.
• Optional SK40A stainless steel oven stand with six-position tray runners and height-adjustable feet allows the unit to be set up as a complete, ergonomic workstation.

Key Features

• Electric direct steam generation — no external boiler required
• 7 x 1/1 GN full-size tray capacity
• Also accommodates 7 x 600mm x 400mm trays
• 70mm tray-to-tray spacing for generous clearance
• Three manual cooking modes: Convection (50°C–260°C), Steam (50°C–130°C), Combi (50°C–260°C)
• Electro-mechanical controls for mode selection, temperature, and timer
• Manual timer range up to 120 minutes
• Auto-reverse fan direction for uniform cooking throughout the chamber
• Door-open rapid cool-down function
• Manual chamber venting
• LED interior chamber lighting
• Smooth cooking chamber walls with fully rounded edges for easy cleaning
• Double-glazed door with thermo-reflective tempered glass for heat retention and operator safety
• Adjustable door hinges for an optimal, consistent door seal
• Manual cleaning system via externally connected hand shower
• Hand shower with triple-action water filter cartridge and filter head included
• Electrical supply: 400–415V, 50Hz, 3P+N+E, 12.5kW, 18A/ph
• Water supply: cold water 3/4" inlet, flow pressure 200–500 kPa
• Drain requirement: funnel waste trap/tundish, 40mm outlet
• Stainless steel construction throughout
• Compatible with optional Turbofan SK40A oven stand (all-stainless welded frame, 6-position tray runners, 4 height-adjustable feet, dimensions 810mm W x 650mm D x 854mm H, supplied CKD for on-site assembly)

Specifications

• Width (mm): 812
• Depth (mm): 725
• Height (mm): 935
• Weight (kg): 340.0
• Shipping Weight: 54.6
• Packed Width (mm): 910.0
• Packed Height (mm): 1050.0
• Packed Depth (mm): 865.0
• Shipping Cubic: 0.826508000m3
• Fuel Type: Electric
• Pan Count: 7
• Pan Size: Full Size GN 1/1
• Voltage/Phase: 400-415V, 50Hz, 3P+N+E, 12.5kW, 18A/ph
