Overview

Turbofan E32T4/2 Double Stacked Full Size Tray Touch Screen Convection Ovens with Adjustable Base Feet

The Turbofan E32T4/2 combines two E32T4 full size tray convection ovens in a double-stacked configuration, delivering a total capacity of 8 full size trays (460 x 660mm / 18" x 26") within a compact 735mm wide footprint. Manufactured in New Zealand from 304 stainless steel, this electric unit is purpose-built for high-throughput commercial kitchens including bakeries, cafes, restaurants and catering operations where consistent output and reliable performance are essential.

Each oven features an intuitive touch screen interface with both program and manual operating modes, an icon-driven program menu supporting multiple-stage cooking, individual shelf control with shelf timers, a 2-speed bi-directional reversing fan system, and five-level moisture injection for precise humidity management. An Energy Save Set-Back mode reduces running costs during quieter periods, while anti-skid adjustable stainless steel base feet provide a stable, level installation on virtually any commercial kitchen floor.

Key Benefits

• Double-stacked configuration doubles cooking capacity without occupying additional floor space, maximising output in kitchens where space is at a premium.
• Total 8-tray capacity across both ovens allows large batch cooking of baked goods, roasted proteins and prepared meals simultaneously.
• Touch screen controls with programmable multi-stage cooking modes reduce operator error and deliver repeatable, consistent results across every shift.
• Five-level moisture injection combined with fan-forced convection ensures even heat distribution and precise humidity control for bread, pastry and delicate products.
• Individual shelf control and shelf timers give operators granular management over each rack, enabling different products to finish at the correct time.
• 2-speed bi-directional reversing fan system promotes uniform air circulation throughout the oven cavity, eliminating hot spots.
• Energy Save Set-Back mode automatically reduces energy consumption during low-demand periods, lowering operating costs over time.
• Compact 735mm width and stainless steel construction make the unit straightforward to integrate and maintain in busy commercial environments.
• 100% recyclable packaging supports sustainability goals from the point of delivery.

Key Features

• Two E32T4 full size convection ovens factory double-stacked as a single unit
• Each oven accommodates 4 x full size sheet pans (460 x 660mm / 18" x 26") or 4 x 600 x 400mm trays, totalling 8 trays across the stack
• 110mm tray spacing per shelf level
• Touch screen control panel with icon-driven program menu
• Both program mode and manual mode operation
• Multiple-stage cooking programs for complex recipe management
• Individual shelf control with dedicated shelf timers
• 2-speed bi-directional reversing fan system for uniform air circulation
• Five-level moisture injection for adjustable humidity during cooking
• Energy Save Set-Back mode to reduce power consumption during idle periods
• 6.3kW heating power per oven
• Single phase power supply: 1P+N+E, 230–240V, 27A, 50Hz, 6.5kW (combined unit rating); no cordset supplied
• Body and structure constructed from 304 stainless steel
• Double-glazed oven doors
• Anti-skid adjustable stainless steel base feet, 50mm diameter x 76mm high
• 4 oven wire racks supplied per oven (8 total)
• 100% recyclable packaging
• Manufactured in New Zealand

Specifications

• Width (mm): 735
• Depth (mm): 858
• Height (mm): 1720
• Weight (kg): 353.0
• Colour: Stainless Steel
• Gas Type: N/A (Electric)
• Gas Connection: N/A (Electric)
• Material: 304 Stainless Steel
• Country of Origin: New Zealand
• Warranty (months): 12
• Fuel Type: Electric
• Power Rating: 1P+N+E|230-240V|27A No cordset supplied|50Hz|6.5kW
• Power Supply: Single Phase 230-240V
• Voltage (V): 230
