Eswood ES25 Pass-Through Warewasher

The Eswood ES25 is an Australian-designed and built pass-through warewasher engineered for the continuous, high-volume demands of busy commercial kitchens. Its compact upright footprint supports both in-line and corner installation, making it easy to integrate into a wide range of dishroom layouts without sacrificing throughput capacity.

Automatic operation begins the moment the hood closes, running selectable 90 or 120 second wash cycles to suit varying load levels. A full suite of standard fittings including detergent and rinse-aid pumps, wash and rinse pumps, automatic tank fill, and digital wash and rinse temperature controllers ensures consistent cleaning results, straightforward HACCP temperature recording, and reliable food-safe performance every service.

Key Benefits

• Pass-through configuration supports continuous loading and unloading during peak service, maximising throughput with minimal interruption
• Corner and in-line installation flexibility lets you configure the dishroom to suit the available space and workflow direction
• Automatic cycle start on hood closure reduces handling steps and keeps the wash process moving without manual intervention
• Selectable 90 and 120 second wash cycles allow staff to match cycle length to the soil level of each load, balancing speed and cleaning effectiveness
• Digital wash and rinse temperature displays make HACCP temperature monitoring and recording quick and accurate for compliance purposes
• Operation interlocked to rinse temperature prevents the cycle completing unless the correct sanitising temperature is reached, supporting food safety standards
• Easily removable spray arms and filters simplify routine cleaning and maintenance, reducing downtime between services
• Gravity drain as standard with an optional drain pump gives installation flexibility across different plumbing configurations
• Supplied ready to use with a plate rack, cup rack and cutlery container so the machine is operational from day one without additional rack purchases

Key Features

• Australian designed and manufactured construction
• Suitable for both in-line and corner pass-through installation
• Counter-balanced lift-up hood with ergonomically designed wrap-around handle for easy one-handed loading
• All stainless-steel body construction and wash arms for durability and hygiene
• Independent upper and lower spray arms for thorough wash and rinse coverage across every rack
• Easily removable spray arms and filters for fast, tool-free cleaning
• Automatic fill to wash and rinse tanks
• 30 litre tank capacity
• Selectable wash cycles of 90 seconds and 120 seconds
• Machine cycle starts automatically upon closure of the hood
• Operation interlocked to rinse temperature to ensure food-safe sanitising
• Digital wash and rinse temperature controllers and displays
• Detergent and rinse-aid pumps fitted as standard for automatic chemical dosing
• Wash and rinse pumps fitted as standard
• 3.5 litres water consumption per cycle
• Gravity drain standard; optional drain pump available
• Single-phase 15A, 240V electrical connection
• 3.5 kW power rating
• High capacity output of 540 to 700 pieces per hour
• Suitable for meal services of 30 to 40 covers (approximately 25 racks per hour)
• 500 x 500 mm rack size
• Includes 1 x TR14 plate rack (500 x 500 x 100 mm), 1 x TR1 cup rack (500 x 500 x 100 mm), and 1 x CB cutlery container
• WaterMark approved (WM-022833)
• Meets FSANZ and HACCP standards
• Machine weight 103 kg
• Compact footprint of 595 mm wide x 600 mm deep x 1405 mm high
• Height with door open: 1755 mm

Specifications

• Width (mm): 595
• Depth (mm): 600
• Height (mm): 1405
• Weight (kg): 103
• Colour: Stainless Steel
• Gas Connection: N/A (Electric)
• Water Consumption: 3.5L Cycle
• Shipping Weight: 103
• Packed Width (mm): 800.0
• Packed Height (mm): 1580.0
• Packed Depth (mm): 800.0
• Shipping Cubic: 1.011200000m3
• Capacity (Litres): 18 x 250 or 9 x 310 plates; ~30 pax
• Power / Gas Input: 3.5 kW
• Power Supply: 230V 1ph
• Power Rating: 15A Single Phase|240V|3.5kW
• Voltage/Phase: 240V 50Hz Single Phase 15A
• Country of Origin: Australia (Made)
• Warranty (months): 24
• Material: Stainless Steel
• Installation Type: Electric
• Control Type: Electronic
• Fuel Type: Electric
