Overview

Eswood ES25DP Pass-Through Warewasher with Drain Pump

The Eswood ES25DP is an Australian designed and built pass-through warewasher engineered to handle the demands of busy commercial kitchens. It is the drain-pump variant of the ES25, making it the ideal choice for sites where gravity drainage is not available. Single-phase only, it delivers a capacity of up to 540 pieces per hour and supports both in-line and corner installation, giving dishroom designers genuine layout flexibility.

All-stainless-steel construction and easily removable spray arms and filters keep the machine hygienic and straightforward to maintain. Operation is fully automatic, with the wash cycle starting upon closure of the hood, and the cycle interlocked to rinse temperature to ensure every rack meets food-safety requirements. FSANZ, HACCP and WaterMark certifications back the machine's suitability for professional food service environments, and the unit ships complete with a plate rack, cup rack and cutlery container.

Key Benefits

• Integrated drain pump removes the need for gravity drainage, opening up installation options in challenging kitchen layouts.
• Up to 540 pieces per hour throughput keeps up with peak service demands without slowing the pass-through workflow.
• Fully automatic cycle start on hood closure speeds up turnaround and reduces the chance of operator error during busy periods.
• Rinse temperature interlock ensures every cycle meets the minimum sanitising threshold, supporting HACCP compliance and food-safety record keeping.
• Digital wash and rinse temperature displays make monitoring conditions at a glance quick and simple for staff.
• Selectable 90-second or 120-second wash cycles allow operators to balance throughput speed against soil load as service conditions change.
• Easily removable spray arms and filters cut the time spent on daily cleaning and routine maintenance.
• Low water consumption of 3.5 litres per cycle reduces operating costs and supports sustainability targets.
• Corner or in-line pass-through configuration adapts to the available floor plan without requiring specialised accessories.

Key Features

• Australian designed and manufactured for durability in harsh commercial kitchen conditions.
• Drain pump fitted as standard, single-phase (15A, 240V) electrical connection only.
• Pass-through hood design suitable for both in-line and corner installation.
• Counter-balanced lift-up hood with ergonomically designed wrap-around handle.
• Fully automatic cycle initiates upon closure of the hood.
• Selectable wash cycle times of 90 seconds and 120 seconds.
• Operation interlocked to rinse temperature to ensure consistent sanitising results.
• Independent upper and lower stainless-steel spray arms for thorough wash and rinse coverage.
• Dedicated wash pump and rinse pump fitted as standard.
• Detergent and rinse-aid dosing pumps fitted as standard for consistent automatic chemical delivery.
• Automatic fill to both wash and rinse tanks.
• 30-litre wash tank capacity.
• Water consumption of 3.5 litres per cycle.
• 500 x 500 mm rack size accommodates standard commercial racks.
• Digital temperature controllers and displays for both wash and rinse circuits.
• Electromagnetic controls for straightforward, user-friendly operation.
• All-stainless-steel body construction and wash arms for hygiene and longevity.
• Easily removable spray arms and filters for quick daily cleaning.
• FSANZ, HACCP and WaterMark certified.
• Supplied with one plate rack, one cup rack and one cutlery container.
• Dimensions: 595 mm wide x 600 mm deep x 1405 mm high.
• Electrical rating: 3.5 kW.

Specifications

• Width (mm): 595
• Depth (mm): 600
• Height (mm): 1405
• Weight (kg): 103
• Colour: Stainless Steel
• Gas Connection: N/A (Electric)
• Shipping Weight: 103
• Packed Width (mm): 800.0
• Packed Height (mm): 1580.0
• Packed Depth (mm): 800.0
• Shipping Cubic: 1.011200000m3
• Capacity (Litres): 18 x 250 or 9 x 310 plates
• Power / Gas Input: 3.5 kW
• Power Supply: 230V 1ph
• Power Rating: 15A Single Phase|240V|3.5kW
• Voltage/Phase: 240V 50Hz Single Phase 15A
• Country of Origin: Australia (Made)
• Warranty (months): 24
• Material: Stainless Steel
• Installation Type: Electric
• Control Type: Mechanical
• Fuel Type: Electric
