Eswood SW900V Smartwash Pass-Through Dishwasher with Heat Recovery System

The Eswood SW900V Smartwash is a professional pass-through warewasher and the first of its kind in Australia to combine intelligent one-touch operation with a built-in heat recovery system, making it one of the most energy and water efficient options available for high-volume commercial kitchens. Built to Eswood specifications using quality European manufacture, it holds independent SEED certification for ventless and hoodless installation, meaning it can be positioned without a separate exhaust canopy and offers greater flexibility in kitchen layout.

Designed for simplicity and food safety compliance, the SW900V presents an intuitive Smartwash interface displaying both wash and rinse temperatures digitally for straightforward HACCP recording, alongside multiple wash cycle options to handle everything from lightly soiled glassware to heavily soiled pots. At just 2.3 litres of water per rack and a 22-litre tank volume, running costs are kept low, while the 465 mm hood opening accommodates large items such as pots with ease. Overall dimensions are 633 mm (W) x 755 mm (D) x 2265 mm (H) including the heat recovery unit. Benches are not included.

Key Benefits

• The heat recovery system recycles energy captured from dishwasher-generated steam each cycle, saving up to 0.5 kW per hour and reducing ambient kitchen heat.
• Independent SEED certification for ventless and hoodless installation removes the need for a dedicated exhaust canopy, freeing up valuable kitchen space.
• Ultra-low water consumption of just 2.3 litres per rack helps significantly reduce water and utility costs in busy operations.
• The Smartwash interface uses a single-button operation with separate digital readouts for both wash and rinse temperatures, making high-capacity use simple for any staff member and supporting effortless HACCP compliance.
• Double-skinned insulated hood and door drastically reduce both heat and noise emissions, contributing to a more comfortable working environment.
• The six-minute scrub cycle delivers effective cleaning of heavily soiled items without manual pre-soaking, saving labour time.
• A self-cleaning cycle along with easily removable spray arms and filters keeps maintenance quick and hygienic.
• The Thermostop function confirms the set rinse temperature is always achieved, ensuring consistent sanitisation results and food safety confidence.
• Supplied complete with racks, a cutlery container, hoses, detergent and rinse aid so the machine is ready to operate from day one.

Key Features

• Heat recovery system captures and recycles energy from steam produced during the wash cycle.
• Independently certified for ventless and hoodless installation (SEED certification).
• Insulated eco hood reduces energy consumption by up to 0.5 kW per hour and suppresses noise.
• Double-skinned door and hood construction significantly reduce heat and sound emissions.
• Single-touch Smartwash interface with separate digital temperature readouts for wash and rinse phases.
• Thermostop function ensures the set rinse temperature is consistently achieved.
• Three timed wash cycles: 90, 120 and 180 seconds.
• Extra special 6-minute scrub cycle for heavily soiled items.
• Self-cleaning cycle for simplified daily maintenance.
• Easily removable spray arms and filters for fast, thorough cleaning.
• Built-in detergent and rinse-aid dispensing pumps fitted as standard.
• Drain pump fitted as standard.
• 22-litre wash tank volume.
• Wash pump power: 700 W; total rated power: 10.2 kW.
• Electrical connection: 415 V / 50 Hz / 3-phase + E + N.
• 465 mm hood opening accommodates large items such as gastronorm trays and pots.
• Compatible with standard 500 x 500 mm racks for both plates and glassware.
• Supplied with a power lead, inlet and outlet hoses, detergent, rinse aid, drain pumps, 500 x 500 mm plate and glass racks, and a cutlery container.
• Quality European manufacture built to Eswood specifications.
• Overall dimensions: 633 mm (W) x 755 mm (D) x 2265 mm (H) including heat recovery unit.
• Benches not included.

Specifications

• Width (mm): 633
• Depth (mm): 755
• Height (mm): 2265
• Weight (kg): 146
• Colour: Stainless Steel
• Gas Connection: N/A (Electric)
• Water Consumption: 2.3L Per Rack
• Shipping Weight: 200
• Packed Width (mm): 850.0
• Packed Height (mm): 2380.0
• Packed Depth (mm): 960.0
• Shipping Cubic: 1.942080000m3
• Capacity (Litres): 16 x 300 or 8 x 280 plates
• Power / Gas Input: 10.2 kW
• Power Supply: 400V 3ph
• Power Rating: 3 phase|6.7 Kw
• Voltage/Phase: 415V 50Hz 3 Phase
• Country of Origin: Australia (Made)
• Warranty (months): 24
• Material: Stainless Steel
• Installation Type: Electric
• Control Type: Electronic
• Fuel Type: Electric
