Fagor FWC-2301-1WB Single Zone 1 Door Black Wall-Mounted Wine Cellar

The Fagor FWC-2301-1WB is a single-zone, wall-mounted wine cellar designed to display and preserve wine at its finest in restaurants, bars, and hospitality venues. With a capacity of 63 bottles across nine shelves, this tall black cabinet operates across a temperature range of 4°C to 18°C and is rated for ambient conditions up to 40°C, making it well suited to the demands of a busy commercial environment.

Built around a ventilated refrigeration system with automatic defrost and evaporation, the FWC-2301-1WB requires no drain connection and is straightforward to position. Its double-layered glass walls with air chambers, heated door frames, and perimeter LED lighting combine to create an attractive, condensation-free display that elevates the perceived value of every bottle on show.

Key Benefits

• Ventilated refrigeration maintains a consistent temperature throughout the cabinet, protecting wine quality during busy service periods.
• Heated glasses and door frames actively prevent condensation from forming, keeping the display clear and visually appealing at all times.
• Automatic defrost with a self-evaporating water collection tray eliminates the need for manual defrosting and removes the requirement for a drain connection, simplifying installation.
• Perimeter LED lighting adjustable via remote control lets staff fine-tune the ambience of the display without opening the cabinet.
• An optional humidity control feature allows operators to dial in the ideal conservation environment for long-term wine storage.
• An independent digital thermostat gives precise temperature management for the storage zone, ensuring wines are served at the correct temperature.
• Swing doors are designed to optimise the use of available floor space, practical in tight kitchen or front-of-house areas.
• A decorative plinth is included as standard, providing a polished finished appearance straight out of the box.
• A four-year warranty package (two years parts and labour plus two years parts only, upon registration within 14 days of invoice) provides strong long-term coverage for commercial operators.

Key Features

• Single-zone configuration with one hinged swing door.
• Wall-mounted, fixed installation on legs; Colorbond body construction.
• Double-layered glass on side and central walls with an insulating air chamber between panes.
• Heated glass panels and door frames to prevent condensation build-up.
• Ventilated refrigeration system for even, consistent cooling throughout the cabinet.
• Temperature range of 4°C to 18°C; rated for ambient temperatures up to 40°C at 40% relative humidity.
• Independent digital thermostat for precise zone temperature control.
• Optional humidity control for an optimised long-term wine conservation environment.
• Automatic defrost with a water collection tray and automatic evaporation; no drain connection required.
• Perimeter LED lighting across all interior edges, adjustable via remote control.
• Capacity of 7 bottles per shelf across 9 shelves (63 bottles total).
• Decorative plinth included as standard; shelves and hooks available as separate accessories.
• 240V / 10A single-phase power supply; 1.28W rated power.
• Auto defrost cycle.
• Dimensions: 862mm wide x 632mm deep x 2300mm high; unit weight 539.75kg.
• Packed dimensions: 800mm wide x 1005mm deep x 2685mm high.
• Warranty: 2 years parts and labour plus 2 years parts only, with product registration required within 14 days of invoice.

Specifications

• Width (mm): 862
• Depth (mm): 632
• Height (mm): 2300
• Weight (kg): 539.75
• Packed Width (mm): 800
• Packed Depth (mm): 2685
• Packed Height (mm): 1005
• No. of Doors: 1
• Door Type: Hinged Doors
• Body Material: Colorbond
• Mobility: Fixed/Legs
• Defrost Type: Auto
• Power Delivery: 240V; 1.28W ; 10A
• Power (kW): 240
• Warranty (months): 2 Years Parts and Labour + 2 Years Parts Only for Products Registered within 14 Days of Invoice
• Mounting Type: Wall Mounted
