Blue Seal G516A-CB Evolution Series 900mm Gas Griddle Cooktop with Cabinet Base

The Blue Seal G516A-CB is a 900mm commercial gas griddle cooktop sitting atop a fully enclosed stainless steel cabinet unit, and forms part of the well-regarded Evolution Series range. Three independent 20MJ/hr griddle burners combine for a total output of 60MJ/hr (16.6kW), powering a smooth machined mild steel griddle plate that delivers rapid heat-up, even heat distribution, and the cooking capacity required for high-volume breakfast service, burgers, steaks, seafood, and beyond.

Engineered for the rigours of commercial kitchens in restaurants, cafés, pubs, and catering venues, the G516A-CB pairs heavy-duty stainless steel construction with practical features including push-button piezo ignition and flame failure protection across all burners. The integrated enclosed base offers generous underbench storage space for cookware, trays, and kitchen essentials, supporting a more organised and efficient workflow. The unit is available in Natural Gas or LPG configurations and accepts an optional GN 1/1 racking kit, making it a flexible, durable choice for busy service environments.

Key Benefits

• Three high-output 20MJ/hr griddle burners deliver fast heat-up and strong heat recovery, keeping pace with high-volume service demands.
• Flame failure protection on every burner automatically cuts the gas supply if a flame goes out, improving kitchen safety throughout busy service periods.
• Push-button piezo ignition allows quick, reliable burner lighting without the need for matches or a separate lighter.
• The enclosed cabinet base provides a ready-access storage compartment beneath the cooktop, keeping cookware, trays, and kitchen supplies organised and within reach to streamline workflow.
• Optional GN 1/1 racking kit compatibility adds flexibility to the cabinet base, supporting structured storage of gastronorm containers.
• Adjustable feet and two rear rollers make installation straightforward and allow the unit to be repositioned for cleaning or servicing with minimal effort.
• Removable heavy-duty cast iron burners and robust vitreous enamel pot stands simplify routine cleaning and component replacement, reducing downtime.
• Heavy-duty reinforced control knobs fitted with strengthened shaft sleeves allow precise heat adjustment across the full temperature range and are built to withstand the demands of daily commercial use.
• Modular Evolution Series design allows the unit to sit alongside other 900mm Blue Seal Evolution components for a coordinated, space-efficient cooking suite.

Key Features

• 900mm smooth machined mild steel griddle plate on an enclosed cabinet base
• 3 independent griddle burners each rated at 20MJ/hr; combined gas rating 60MJ/hr (16.6kW)
• Available in Natural Gas or LPG — specify gas type at time of ordering
• Push-button piezo ignition on griddle burners
• Flame failure protection on all burners
• Heavy-duty stainless steel construction throughout
• Removable heavy-duty cast iron burners
• Vitreous enamel pot stands
• Heavy-duty reinforced control knobs with strengthened shaft sleeves
• Fully enclosed stainless steel cabinet base with generous underbench storage capacity
• Compatible with optional GN 1/1 racking kits for organised tray storage
• Adjustable feet and 2 rear rollers for levelling and repositioning
• Dimensions: 900mm W x 812mm D x 915mm H (1085mm H including splashback)
• Designed for easy cleaning, installation, and servicing
• Part of the modular Blue Seal Evolution Series for suite configuration

Specifications

• Width (mm): 900
• Depth (mm): 812
• Height (mm): 1085
• Weight (kg): 396.0
• Shipping Weight: 245
• Packed Width (mm): 945.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 1.031798000m3
