Goldstein PF36G240EFF-X 800 X-Series 1005mm (40in) Electric Fan Forced Oven Range

The Goldstein PF36G240EFF-X is part of the Australian-made 800 X-Series and combines a 40-inch (1005mm) electric fan forced oven with two high-performance gas cooktop burners and a substantial 914 x 520 x 20mm thick mild steel griddle plate, all within a 1219mm wide unit. Designed for the rigours of busy commercial kitchens, the range features a fully welded stainless steel body with a modular cooktop layout that accommodates various burner, griddle, and chargrill configurations to suit different service demands.

Built in Australia and engineered for reliability, the X-Series delivers consistent cooking performance across every section of the range. The electric fan forced oven provides even heat distribution throughout a gastronorm-compatible cavity, while safety features including pilot flame failure protection on open burners and oven burner, along with piezo ignition throughout, make daily operation practical and efficient. Stainless steel fascia, drip trays, and vitreous enamel oven lining simplify cleaning and support a hygienic kitchen environment.

Key Benefits

• The 914mm mild steel griddle plate and two 33 MJ gas burners offer versatile, high-output cooking across multiple food types simultaneously.
• The 40-inch electric fan forced oven circulates heat evenly, reducing hot spots and delivering consistent baking and roasting results batch after batch.
• GN 1/1 compatible oven cavity with three-position racking maximises usable oven space and accommodates standard gastronorm trays for streamlined workflow.
• Constant pilot flame design maximises energy efficiency and ensures the range is ready for rapid deployment during peak service periods.
• Pilot flame failure protection on open burners and the oven burner provides an important safety layer in high-pressure kitchen environments.
• Fully welded stainless steel construction with welded griddle and chargrill surrounds resists warping and structural wear over years of heavy daily use.
• Adjustable legs ranging from 140 to 170mm allow the unit to be levelled precisely on uneven kitchen floors.
• Vitreous enamel lining on the oven interior and door simplifies cleaning and helps maintain even heat distribution throughout the cavity.
• Modular cooktop design supports a range of configurations across 305, 610, 914, and 1219mm sections, giving operators flexibility as kitchen needs evolve.

Key Features

• Australian-made Goldstein 800 X-Series construction
• Heavy duty fully welded stainless steel body for long-term rigidity and durability
• Stainless steel fascia and sides throughout
• Two removable 33 MJ high-performance gas cooktop burners with even heat distribution
• 40% of burner flame ports positioned in the centre cross for improved heat spread
• Cast iron star trivets on cooktop burners
• 914 x 520 x 20mm thick mild steel griddle plate
• 20 MJ griddle burners per every 305mm griddle section
• Piezo ignition on griddle plate
• Griddle and BBQ section positioned on the left-hand side
• 40-inch (1005mm) electric fan forced oven
• 100°C to 280°C thermostatic oven temperature control
• Piezo ignition on oven burner
• Fully insulated oven and door with vitreous enamel lining for even heat and easy cleaning
• GN 1/1 gastronorm compatible oven cavity
• Three-position oven racking
• Heavy duty chrome wire rack supports designed for easy removal
• Constant pilot flame for operating and energy efficiency
• Pilot flame failure safety on open burners and flame failure protection on oven burner
• Fully welded surrounds for griddle and chargrill options
• Flexible modular cooktop design supporting 305, 610, 914, and 1219mm configurations
• Large heat-resistant reinforced control knobs with clearly visible high-to-low flame settings
• Ergonomic door handle and angled corners for a refined appearance
• Spill zone and drip trays for straightforward cleaning
• Adjustable legs from 140 to 170mm for level installation
• Accessible design to facilitate servicing
• Available oven configurations include gas fan forced (PF36G240FF-X), electric fan forced (PF36G240EFF-X), electric convection (PFC36G240E-X), and electric static (PF36G240E-X)

Specifications

• Width (mm): 1219
• Depth (mm): 850
• Height (mm): 1120
• Weight (kg): 269
• Power / Gas Input: 126/126 MJ; 8.8 kW
• Country of Origin: Australia (Made)
