Overview

Goldstein PF24Q440FF-X 800 X-Series 1005mm (40in) Fan Forced Gas Oven Range with 4 Burners & 610mm Chargrill

The Goldstein PF24Q440FF-X is part of the Australian-made 800 X-Series and combines four high-performance gas cooktop burners with a 610mm (24in) cast iron chargrill and a 1005mm (40in) fan forced gas oven into a single 1219mm-wide heavy-duty range. The modular cooktop design supports various combinations of burners, griddle plates and chargrill sections, making this unit a versatile centrepiece for high-volume commercial kitchens.

Built on a fully welded stainless steel body with stainless steel fascia and sides, the PF24Q440FF-X is engineered for rigidity, daily durability and straightforward servicing. The fan forced oven delivers even heat distribution across a GN 1/1 compatible cavity with thermostatic control from 100°C to 280°C, while constant pilot flames and flame failure safety devices on both open burners and the oven burner maximise operational efficiency and safety.

Key Benefits

• Fan forced gas oven ensures consistent, even heat for reliable baking and roasting across the full cavity, reducing hot spots and improving batch consistency.
• Four 33 MJ cooktop burners with 40% of flame ports concentrated in the centre cross deliver even heat and peak productivity for high-turnover service periods.
• 610mm chargrill with heavy duty reversible cast iron grates and two inline 20 MJ radiant burners per 305mm section provides intense, controllable heat for chargrilling at volume.
• Constant pilot flame operation maximises energy efficiency and eliminates re-ignition delays during busy service.
• Flame failure safety devices on open burners and the oven burner protect kitchen staff and comply with commercial safety requirements.
• Fully welded stainless steel body with spill zones and removable drip trays simplifies cleaning and reduces downtime between services.
• GN 1/1 compatible oven cavity with three-position racking and easily removable chrome wire rack supports allows flexible loading of standard gastronorm pans.
• Adjustable legs from 140mm to 170mm allow levelling on uneven kitchen floors, supporting stable operation and correct alignment with surrounding equipment.
• Australian-made construction with an easy-to-service design reduces maintenance costs and supports local spare parts availability.

Key Features

• 4 x 33 MJ removable high-performance cooktop burners with even heat distribution; 40% of flame ports located in the centre cross of each burner for consistent output.
• Cast iron star trivets on cooktop burners for stable pan support.
• 610mm (24in) BBQ/chargrill section with heavy duty reversible cast iron grates offering flat or gradient levelling options.
• 2 x 20 MJ inline radiant burners per 305mm chargrill section.
• Optional ceramic rocks on chargrill to increase heat retention and enhance flavour.
• 1005mm (40in) fan forced gas oven with thermostatic control from 100°C to 280°C.
• Piezo ignition on oven burner.
• Oven cavity and door fully insulated with vitreous enamel lining for even heat distribution and easy cleaning.
• GN 1/1 oven capacity with 3-position racking system.
• Heavy duty chrome wire rack supports designed for easy removal and cleaning.
• Constant pilot flame on cooktop burners for maximised operating and energy efficiency.
• Pilot flame failure safety device on open burners; flame failure device on oven burner.
• Fully welded heavy duty stainless steel body for rigidity and long-term durability.
• Fully welded surrounds for griddle and chargrill sections.
• Stainless steel fascia and sides.
• Spill zone and removable drip trays for ease of cleaning.
• Large heat-resistant reinforced control knobs with clearly visible high-to-low flame settings.
• Ergonomic door handle and angled corners for a streamlined appearance.
• Chargrill and BBQ section positioned on the left-hand side of the cooktop.
• Flexible modular cooktop design supports various combinations of burners, griddle plates and chargrill options (305mm, 610mm and 914mm configurations).
• Adjustable legs from 140mm to 170mm for levelling on uneven surfaces.
• Designed for easy servicing and maintenance.
• Made in Australia.
• Total gas input: 247/244 MJ; 0.043 kW electrical input.
• Dimensions: 1219mm wide x 850mm deep x 1120mm high.

Specifications

• Width (mm): 1219
• Depth (mm): 850
• Height (mm): 1120
• Weight (kg): 378
• Power / Gas Input: 247/244 MJ; 0.043 kW
• Country of Origin: Australia (Made)
