Overview

Goldstein PF36G28E-X 800 X-Series 914mm Griddle with 700mm Electric Static Oven Range

The Goldstein PF36G28E-X is an Australian-made commercial oven range from the 800 X-Series, combining a full 914mm mild steel griddle section with a 700mm electric static oven. Built on a heavy-duty welded stainless steel body, this unit is engineered for the demands of high-volume commercial kitchens, delivering consistent cooking performance across both the griddle and oven simultaneously.

The X-Series platform is designed with flexibility in mind, supporting modular cooktop configurations across 305mm, 610mm and 914mm increments, and offering a choice of static, fan forced or convection oven options to suit different kitchen requirements. From the vitreous enamel-lined oven cavity to the ergonomic controls and easy-clean drip trays, every element is tailored for practical, reliable daily operation.

Key Benefits

• Full 914mm griddle surface delivers high-capacity simultaneous cooking for busy service periods
• Electric static oven with 100°C to 280°C thermostatic control provides precise, consistent baking and roasting temperatures
• GN 1/1 compatible oven cavity with three-position racking maximises versatility for gastronorm cookware
• Vitreous enamel-lined oven interior and door retain even heat and simplify post-service cleaning
• Constant pilot flame on burners improves energy efficiency and ensures reliable ignition during service
• Pilot flame failure on open burners and flame failure on oven burner add an important layer of operational safety
• Adjustable legs from 140mm to 170mm allow levelling on uneven kitchen floors
• Stainless steel fascia, sides, spill zones and drip trays make daily cleaning straightforward and fast
• Modular X-Series design supports future reconfiguration with different burner, griddle and oven combinations

Key Features

• Australian made unit from the Goldstein 800 X-Series range
• Overall dimensions: 914mm wide x 800mm deep x 1120mm high
• Heavy-duty welded stainless steel body construction providing long-term structural integrity; griddle and chargrill sections feature fully welded surrounds throughout
• Flexible modular cooktop design compatible with 305mm, 610mm and 914mm configurations of burners, griddle plates and chargrill options
• 914 x 520 x 20mm thick mild steel griddle plate for even, consistent heat across the full surface
• 20 MJ griddle burners per 305mm section
• Piezo ignition on griddle burners
• Griddle and BBQ section positioned on the left-hand side
• 700mm electric static oven with 100°C to 280°C thermostatic control
• Piezo ignition on oven burner
• Oven and door fully insulated and lined with vitreous enamel, ensuring uniform heat retention and straightforward post-service cleanup
• GN 1/1 oven capacity with three-position racking; oven rack supports are constructed from heavy-duty chrome wire and can be lifted out without tools
• The permanent pilot flame arrangement optimises both running costs and energy consumption; open burners incorporate pilot flame failure protection, and the oven burner includes its own flame failure safety device
• Stainless steel fascia and sides with spill zones and drip trays for straightforward, efficient cleaning
• Large heat-resistant reinforced control knobs with clearly visible settings, offering graduated flame adjustment from maximum to minimum output; the door handle is ergonomically shaped and corners are angled for a clean, professional appearance
• Adjustable legs from 140mm to 170mm to accommodate uneven floors
• Designed for easy servicing and maintenance
• Available oven variants in the X-Series range: gas static (PF36G28-X implied), gas fan forced (PF36G28FF-X), electric fan forced (PF36G28EFF-X), gas convection (PFC36G28-X), electric convection (PFC36G28E-X)
• Total power/gas input: 60 MJ gas / 5.4 kW electric
• Weight: 258kg

Specifications

• Width (mm): 914
• Depth (mm): 800
• Height (mm): 1120
• Weight (kg): 258
• Power / Gas Input: 60/60 MJ; 5.4 kW
• Country of Origin: Australia (Made)
