Overview

Waldorf RN8403E-B 800 Series 600mm Electric Cooktop with Griddle – Bench Model

The Waldorf RN8403E-B is a 600mm bench-mount electric cooktop from the 800 Series, combining two 2.4kW radiant elements with a 300mm griddle section powered by a 3.6kW element. Constructed from 304 stainless steel throughout, with a welded 1.5mm bull-nose hob, 1.2mm splashback and side panels, and a 12mm thick mild steel griddle plate, this unit is engineered for the sustained demands of high-volume commercial kitchens.

Mounted on four heavy-duty 63mm diameter stainless steel bench legs with adjustable feet ranging from 80mm to 105mm in height, the RN8403E-B also includes two additional rollers for ease of repositioning. The griddle section is positioned on the right-hand side as standard, and the design prioritises front-access servicing, hinge-up element and griddle sections, and removable vitreous enamelled spill trays to keep cleaning and maintenance time to a minimum.

Key Benefits

• Combination cooktop and griddle layout in a compact 600mm footprint provides versatile cooking capability without requiring separate appliances.
• Six temperature settings including a simmer setting on each radiant element give cooks precise control for delicate and high-heat tasks alike.
• The 50–320°C thermostat on the 300mm griddle section enables consistent surface temperatures for grilling and searing across the full griddle area.
• Hinge-up element and griddle sections with front-of-unit access to all components reduce downtime during routine servicing and deep cleaning.
• Removable vitreous enamelled element modules and hob spill trays simplify day-to-day cleaning and help maintain hygiene standards under busy service conditions.
• Adjustable bench legs (80–105mm height range) plus two rollers allow easy levelling on uneven surfaces and convenient repositioning within the kitchen.
• Indicator lights for power and heating on each element control let staff monitor operating status at a glance, reducing the risk of accidental energy waste.
• Optional hot plate elements with machine-finished 8mm steel plate offer a straightforward upgrade path as menu or volume requirements change.

Key Features

• 2 x 2.4kW open radiant elements set in heavy-duty welded element frames
• 1 x 3.6kW griddle element powering a 300mm griddle section; griddle positioned on right-hand side as standard
• 12mm thick mild steel griddle plates with 2.5mm 304 stainless steel griddle splash guards
• Six temperature settings per radiant element including a simmer setting, controlled via energy regulators
• 50–320°C thermostat control per 300mm griddle section
• Indicator lights for both power and heating status on each element control
• Welded hob constructed from 1.5mm 304 stainless steel with bull-nose edge
• Splashback and side panels in 1.2mm 304 stainless steel; front panels in 0.9mm 304 stainless steel
• Aluminised steel internal construction
• Vitreous enamelled element module and hob spill trays – removable for cleaning
• Hinge-up element and griddle sections for fast access during service and cleaning
• All serviceable parts accessible from the front of the unit
• Large heat-resistant reinforced control knobs with easy-view settings
• Four 63mm diameter heavy-duty 1.2mm 304 stainless steel bench legs with adjustable feet (80–105mm height adjustment)
• Two additional rollers supplied for repositioning flexibility
• Optional hot plate elements with machine-finished 8mm steel plate available
• Bench model (–B configuration) with heavy-duty stainless steel external finish
• 20A electrical supply requirement

Specifications

• Width (mm): 600
• Depth (mm): 805
• Height (mm): 530
• Weight (kg): 340.0
