Overview

Waldorf RN8513GC 800 Series 750mm Gas Range Convection Oven

The Waldorf RN8513GC is part of the acclaimed 800 Series and combines a 2-burner gas cooktop with a 300mm griddle mounted above a full 1/1 GN gas convection oven, all within a compact 750mm-wide footprint. Patented 28MJ/hr open burners deliver exceptional cooking power on the cooktop, while a heavy-duty motor and circulation fan in the convection oven below enable reduced cooking times and more even results at lower temperatures.

Available in both natural gas and LPG configurations, the RN8513GC is built for the rigours of high-volume commercial kitchens, with a heavy-duty stainless steel finish throughout, flame failure protection on every burner, and a vitreous enamel-lined oven cavity for straightforward cleaning. Adjustable feet and two integrated rollers make positioning and servicing simple, and the unit is designed from the ground up for easy installation and maintenance.

Key Benefits

• Fan-forced convection heat circulates evenly throughout the 1/1 GN oven cavity, reducing cooking times and allowing lower temperature settings for consistent batch results.
• Two high-output 28MJ/hr open burners provide rapid, responsive heat for sauteing, boiling and searing across a range of cookware.
• The 300mm griddle with a dedicated 20MJ/hr burner adds versatile flat-top cooking capacity without requiring additional equipment or floorspace.
• Flame failure protection on all burners automatically cuts gas supply if a flame is extinguished, improving kitchen safety.
• Vitreous enamel oven lining and pot stands resist staining and are straightforward to wipe down, reducing cleaning time between services.
• Adjustable feet combined with two rollers allow precise levelling on site and easy repositioning for cleaning or servicing behind the unit.
• Heavy-duty reinforced control knobs and a welded drop-down oven door frame are built to withstand the demands of continuous commercial use.
• Available in both natural gas and LPG variants, making the unit suitable for a wide range of commercial kitchen installations.
• The cool-touch stainless steel door handle reduces burn risk when accessing the oven during service, supporting a safer working environment.

Key Features

• 2-burner cooktop range with 300mm griddle, all on a 1/1 GN gas convection oven base
• 2 x patented 28MJ/hr open cooktop burners
• 1 x 20MJ/hr dedicated griddle burner
• Griddle positioned on the right-hand side as standard
• 1/1 GN gas convection oven with heavy-duty motor and circulation fan
• Cast iron sole plates in the oven for even heat distribution
• Oven cavity welded and lined with vitreous enamel for durability and easy cleaning
• Flame failure protection on all burners
• Removable heavy-duty cast iron burners
• Vitreous enamel pot stands
• Heavy-duty stainless steel exterior finish
• Drop-down oven door with welded frame
• Cool-touch stainless steel door handle
• Heavy-duty reinforced control knobs
• Adjustable feet with 2 additional rollers for levelling and repositioning
• Electrical requirement: 0.13kW via 3-pin 10A plug cordset fitted
• Available in natural gas and LPG configurations
• Designed for easy cleaning, installation and servicing
• Note: product images may show model RN8510GC

Specifications

• Width (mm): 750
• Depth (mm): 805
• Height (mm): 1130
• Weight (kg): 340.0
• Shipping Weight: 239
• Packed Width (mm): 795.0
• Packed Height (mm): 1255.0
• Packed Depth (mm): 870.0
• Shipping Cubic: 0.868021000m3
