Overview

Waldorf RNL8813G 800 Series 1200mm Gas Range Static Oven Low Back Version

The Waldorf RNL8813G is a heavy-duty 1200mm gas range from the Waldorf 800 Series, combining a six-burner cooktop and a 300mm griddle with a 2/1 GN gas static oven beneath. Manufactured in New Zealand from 304 stainless steel, it is engineered for the demands of high-volume commercial kitchens, delivering consistent cooking performance across both the cooktop and oven cavity.

The cooktop features six patented 28MJ/hr open burners alongside a dedicated 20MJ/hr griddle burner, while the static oven is lined with welded vitreous enamel and fitted with cast iron sole plates for even heat distribution across its full temperature range of 150 to 300°C. A storage cabinet on the right-hand side adds practical utility, and the low back configuration suits kitchens where overhead clearance or sightlines are a priority.

Key Benefits

• Six high-output 28MJ/hr open burners plus a 20MJ/hr griddle burner deliver substantial total heat output across the cooktop for simultaneous multi-dish cooking.
• Cast iron sole plates inside the oven promote even heat distribution, supporting reliable baking and roasting results batch after batch.
• Vitreous enamel oven lining and welded construction make interior cleaning faster and easier, reducing kitchen downtime between services.
• Flame failure protection on all burners enhances safety by automatically cutting gas supply if a flame is extinguished.
• Adjustable feet and two additional rollers allow the unit to be levelled precisely on uneven floors and repositioned without heavy lifting.
• Removable cast iron burners and vitreous enamel pot stands simplify routine maintenance and deep cleaning.
• The 2/1 GN oven capacity with four shelves accommodates large gastronorm trays, supporting high-output catering and batch cooking.
• Heavy-duty reinforced control knobs and a cool-touch stainless steel door handle are built to withstand the rigours of continuous commercial use.
• Compatible with both natural gas and LPG, giving operators flexibility across different site configurations.

Key Features

• Six-burner cooktop range with 300mm griddle, griddle positioned on the right-hand side as standard
• 2/1 GN gas static oven with thermostatic temperature control ranging from 150°C to 300°C
• Six open burners rated at 28MJ/hr each
• One griddle burner rated at 20MJ/hr
• Total burner output of 168MJ/hr; overall power rating 46.7kW
• Cast iron sole plates in the oven cavity for even heat distribution
• Oven cavity lining is fully welded and finished with vitreous enamel for durability and easy cleaning
• Flame failure protection fitted to all burners
• Removable heavy-duty cast iron burners
• Vitreous enamel pot stands
• Heavy-duty reinforced control knobs
• Drop-down oven door with welded frame
• Cool-touch stainless steel door handle
• Storage cabinet on right-hand side
• Four oven shelves included
• Splash back included; low back configuration
• Adjustable feet plus two additional rollers for levelling and mobility
• Constructed from 304 stainless steel throughout
• Gas connection: R 3/4 (BSP) male; compatible with natural gas and LPG
• Analog temperature display
• Dimensions: 1200mm (W) x 805mm (D) x 970-972mm (H)
• Manufactured in New Zealand
• 24-month warranty

Specifications

• Width (mm): 1200
• Depth (mm): 805
• Height (mm): 970
• Weight (kg): 340.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Burner Output (MJ/h): 168
• Material: 304 Stainless Steel
• Undershelf: No
• Door Type: Drop Down
• No. of Shelves: 4
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 24
• Temperature Range: Variable (Cooktop), 150-300°C (Oven)
• Fuel Type: Gas
• Number of Burners: 6
• Griddle Surface: Smooth
• Power Rating: 46.7 kW
• Temperature Control: Thermostatic
• Display Type: Analog
