Waldorf RNL8823G 800 Series 1200mm Gas Range Double Static Oven Low Back Version

The Waldorf RNL8823G is a heavy-duty 1200mm gas range from the 800 Series, combining a six-burner cooktop and a 300mm griddle plate with two 1/1 GN gas static ovens in a low back configuration. Constructed from 304 stainless steel and manufactured in New Zealand, it is engineered for the sustained demands of high-volume commercial kitchens.

Designed for straightforward operation and maintenance, the unit features flame failure protection across all burners, vitreous enamel oven linings and pot stands, cool touch door handles, and adjustable feet with two additional rollers for easy repositioning. The griddle is positioned on the right-hand side as standard, and the drop-down oven door with welded frame adds to the robust, practical build.

Key Benefits

• Six open burners at 28 MJ/hr each deliver high, responsive heat output across multiple cooking zones simultaneously, supporting fast-paced service.
• Two 1/1 GN static ovens provide generous combined capacity for baking, roasting and finishing dishes, reducing bottlenecks during busy service periods.
• The 300mm griddle with a dedicated 20 MJ/hr burner adds a versatile flat cooking surface without requiring a separate piece of equipment, saving bench space.
• Flame failure protection on every burner shuts off the gas supply if a flame extinguishes, improving kitchen safety and compliance.
• Vitreous enamel oven linings and pot stands resist staining and are easy to wipe down, reducing cleaning time between services.
• Adjustable feet and two additional rollers allow the unit to be levelled precisely and repositioned for cleaning or reconfiguration without heavy lifting effort.
• Heavy-duty reinforced control knobs and a welded door frame withstand the rigours of continuous commercial use, minimising the risk of damage over time.
• Thermostatic oven temperature control with an analogue display provides straightforward, reliable temperature management across the 150-300°C range.
• Compatibility with both natural gas and LPG via an R 3/4 BSP male connection gives flexibility for different site gas supplies.

Key Features

• Six open burners each rated at 28 MJ/hr, with removable heavy-duty cast iron burner heads
• Vitreous enamel pot stands, removable for cleaning
• 300mm griddle plate positioned on the right-hand side as standard, powered by a dedicated 20 MJ/hr burner with smooth surface
• Two 1/1 GN gas static ovens with welded, vitreous enamel-lined interiors
• Four oven shelves included
• Total burner output of 168 MJ/hr (46.7 kW)
• Thermostatic oven temperature control, 150-300°C range
• Analogue temperature display
• Flame failure safety protection on all burners
• Drop-down oven door with welded frame
• Cool touch stainless steel oven door handle
• Heavy-duty reinforced control knobs
• 304 stainless steel construction with heavy-duty stainless steel finish
• Low back (splash back) configuration
• Adjustable feet plus two additional rollers for levelling and repositioning
• Compatible with natural gas and LPG; R 3/4 (BSP) male gas connection
• 1200mm wide x 805mm deep x 972mm high; packed weight 383 kg
• Total volume 1.36 m³
• Manufactured in New Zealand
• 24-month warranty

Specifications

• Width (mm): 1200
• Depth (mm): 805
• Height (mm): 970
• Weight (kg): 383.0
• Colour: Stainless Steel
• Gas Type: LPG|Natural Gas
• Gas Connection: R 3/4 (BSP) male
• Burner Output (MJ/h): 168
• Material: 304 Stainless Steel
• Undershelf: No
• Door Type: Drop Down
• No. of Shelves: 4
• Splash Back: Yes
• Country of Origin: New Zealand
• Warranty (months): 24
• Temperature Range: Variable (Cooktop), 150-300°C (Oven)
• Fuel Type: Gas
• Number of Burners: 6
• Griddle Surface: Smooth
• Power Rating: 46.7 kW
• Temperature Control: Thermostatic
• Display Type: Analog
