Overview

Skope TME1000N-AC ActiveCore 2 Glass Door Display or Storage Fridge with Lit Sign

The Skope TME1000N-AC is a top-mounted, self-contained, double glass door display fridge built around Skope's ActiveCore 3 refrigeration platform, delivering 896 litres of usable space in a 1130 mm wide footprint. Suited to restaurants, cafés, bars, pubs, clubs, quick service restaurants, and retail environments, it operates in ambient temperatures up to 40°C and holds product at a food-safe 1°C to 4°C, adjustable to 15°C via the SKOPE-connect smartphone app.

The cabinet is constructed from powder-coated galvanised steel with a stainless steel finish, and features frameless, double-glazed, argon-filled, low-e insulated glass doors for maximum product visibility and condensation protection. An illuminated top-mounted sign panel accepts custom backlit branding, while two interior LED strips and Bluetooth-connected smart control make this fridge as practical for front-of-house presentation as it is for back-of-house storage.

Key Benefits

• Frameless double-glazed glass doors maximise product visibility and protect against condensation, driving impulse purchase and reducing maintenance.
• SKOPE-connect Bluetooth app lets operators set temperatures, schedule LED lighting on/off times, configure alerts, and monitor energy consumption remotely from a smartphone.
• R290 natural refrigerant delivers ultra-low energy draw (0.72 kW), low heat discharge, and reduced noise, keeping running costs to an estimated $435 per year at $0.30/kWh.
• Top-mounted, fully removable, modular ActiveCore refrigeration cartridge allows safe and rapid servicing of flammable refrigerant in line with best practice, minimising business disruption.
• The same interchangeable cartridge is used across Skope's 600 L to 1500 L fridge range, so technicians can service units faster with familiar components.
• Ten half-width shelves per unit (five per door) adjust easily via ezi-clip numbered shelf supports, enabling flexible merchandising of different product sizes.
• Climate Class 5 tested and GEMS Class 3M1 certified, confirming reliable performance in tropical ambient conditions up to 40°C across Australian and New Zealand markets.
• Built-in illuminated sign panel with a dedicated 12 W LED strip provides a ready-to-brand lightbox for promotional graphics without additional signage investment.
• Certified to Australian and New Zealand refrigeration and electrical safety standards, providing confidence for commercial compliance in any hospitality or retail setting.

Key Features

• ActiveCore 3 top-mounted, integral, fully removable modular refrigeration unit (model UTHCNI-0010)
• 2 frameless glass doors with double-glazed, argon-filled, low-e insulated panels for condensation protection
• 896 litre gross capacity across a 0.84 m² floor area
• 10 half-width plastic-coated wire shelves (500 W x 470 D mm), five per door, adjustable via ezi-clip numbered shelf supports
• Temperature range 1°C to 4°C standard; adjustable 1°C to 15°C via SKOPE-connect app
• R290 natural refrigerant, 99 g charge
• Fan-assisted cooling with automatic defrost
• Interior lighting: 2 x 1400 mm, 15 W LED strips
• Illuminated top sign panel: 1 x 1060 mm, 12 W LED, accommodates custom backlit branding graphics
• SCS Connect smart controller with SKOPE-connect app compatibility via Bluetooth wireless technology
• App functions include temperature setting, lighting scheduling, energy monitoring, and alert configuration
• GEMS Class 3M1 certified; GEMS energy consumption 3.97 kWh/24 h
• Estimated annual running cost $435 p.a. at $0.30/kWh
• Maximum ambient operating temperature 40°C; Climate Class 4 (Tropical) certified, tested to Climate Class 5
• M1 compliance for food storage applications
• Power supply: 220–240 V a.c., 50 Hz, single-phase; 0.72 kW, 3.0 A
• Supplied with 2.3 m, 10 A plug and lead
• Cabinet body: powder-coated galvanised steel; exterior finish: 304 stainless steel
• Weight: 225 kg
• Suitable for front-of-house display and back-of-house storage in restaurants, cafés, bars, pubs, clubs, and quick service restaurants
• Certified to Australian and New Zealand refrigeration and electrical safety standards

Specifications

• Width (mm): 1130
• Depth (mm): 745
• Height (mm): 2200
• Weight (kg): 225
• Colour: Stainless Steel
• Gas Type: R290
• Capacity (Litres): 896
• No. of Doors: 2
• Door Type: Glass
• Shelf Configuration: 10 × half width shelf (500W × 470D)
• Body Material: Powdercoat galvanised steel
• Material: 304 Stainless Steel
• No. of Shelves: 4
• Power (kW): 0.72
• Amps (A): 3
• Power Cord: Supplied with 2.3m, 10 Amp plug and lead
• Power Supply: 220-240 Volts a.c. 50 Hz, single phase supply
• Refrigeration Type: Self-Contained
• Max Ambient Temp (°C): 40°C
• Temperature Range: 1°C to 4°C (adjustable with SKOPE-connect 1°C to 15°C)
• Refrigerant: R290 / 99g (natural refrigerant)
• Defrost Type: Automatic
• Climate Class: 4 (Tropical)
• Cooling Type: Fan-assisted
• GEMS Class: 3M1
• GEMS Energy Consumption: 3.97
• GEMS Annual Running Cost: $435 p.a. (@$0.30/KwH)
• Warranty (months): 5 Year
• Country of Origin: China
• Energy Consumption (kWh/24h): GEMS Certified
• Interior Lighting: 2 x 1400mm, 15W LED
• Control Type: SCS Connect (SKOPE-connect compatiable)
• Connectivity: Bluetooth® wireless technology
