Skope TMF1500N-AC ActiveCore 3 Glass Door Display or Storage Freezer with Lit Sign

The Skope TMF1500N-AC is a heavy-duty upright display and storage freezer built on Skope's ActiveCore platform, delivering a new standard of quiet, efficient frozen storage for hospitality and retail environments. Its three full-height glass doors provide maximum product visibility across 1396 litres of gross capacity, while the top-mounted, integral and fully removable ActiveCore freezer cartridge simplifies servicing and keeps the sales floor unobstructed.

Powered by a digital inverter compressor for precise temperature control and featuring active condensation control, the TMF1500N-AC maintains temperatures between -21°C and -18°C in ambient conditions up to 40°C, making it well suited to tropical and demanding commercial kitchens. SKOPE-connect Bluetooth compatibility extends the temperature range to -26°C to -12°C, activates Hush Mode to reduce noise, and gives operators remote monitoring and control from a smart device.

Key Benefits

• Three full-height glass doors maximise frozen product visibility and drive impulse purchases without compromising temperature retention.
• ActiveCore digital inverter compressor delivers precise temperature control and reduced energy consumption compared to fixed-speed alternatives.
• SKOPE-connect Bluetooth connectivity allows operators to monitor temperatures, adjust settings, and activate Hush Mode remotely via a smart device.
• Hush Mode reduces operational noise from 67 dB down to 65 dB, improving comfort in customer-facing environments.
• Top-mounted, integral and removable ActiveCore freezer cartridge simplifies maintenance and reduces downtime during servicing.
• Active condensation control minimises moisture build-up on glass doors, keeping product displays clear and reducing cleaning frequency.
• R290 natural refrigerant delivers strong environmental credentials with a very low global warming potential.
• GEMS Class L1 rating with an annual energy consumption of 31.35 kWh/24h keeps running costs to an estimated $3,433 per year at $0.30/kWh.
• Bright LED interior strip lighting and a dedicated illuminated sign panel enhance product presentation and brand visibility on the retail floor.

Key Features

• Three full-height glass doors suitable for display or storage applications
• ActiveCore technology platform with top-mounted, integral, removable freezer cartridge
• Digital inverter compressor for precise temperature control and energy efficiency
• Active condensation control to keep glass doors clear
• Temperature range: -21°C to -18°C standard; adjustable -26°C to -12°C with SKOPE-connect
• Maximum ambient operating temperature: 40°C (Climate Class 4 Tropical)
• Refrigerant: R290 natural refrigerant (low global warming potential)
• Self-contained refrigeration system
• Automatic defrost
• Fan-assisted cooling
• Interior lighting: 3 x 20 W, 1400 mm LED strip side lights
• Sign lighting: 1 x 24 W, 1590 mm LED strip (lit sign included)
• SCS Connect controller, SKOPE-connect compatible
• Bluetooth wireless connectivity for remote monitoring and control
• Hush Mode via SKOPE-connect reduces noise from 67 dB to 65 dB
• 15 shelves total, 5 shelves per door section
• Gross capacity: 1396 litres
• Body material: powder-coated galvanised steel
• Exterior finish: 304 stainless steel
• Power supply: 220-240 V AC, 50 Hz, single-phase
• Current draw: 11.5 amps
• Power: 2.76 kW
• 2.3 m power cord with 3-pin, 15-amp plug
• GEMS Class: 3L1
• GEMS energy consumption: 31.35 kWh/24h
• Estimated annual running cost: $3,433 p.a. at $0.30/kWh
• Total floor area: 1.27 m²
• Dimensions: 1705 mm W x 745 mm D x 2210 mm H
• Weight: 120 kg

Specifications

• Width (mm): 1705
• Depth (mm): 745
• Height (mm): 2210
• Weight (kg): 120
• Colour: Stainless Steel
• Gas Type: R290
• Capacity (Litres): 1396
• No. of Doors: 3
• Door Type: Glass
• Shelf Configuration: 5 (per door)
• Body Material: Powder coated galvanised steel
• Material: 304 Stainless Steel
• No. of Shelves: 15
• Power (kW): 2.76
• Amps (A): 11.5
• Power Cord: 2.3 m power cord with 3-pin, 15 amp plug
• Power Supply: 220-240 volts a.c., 50 Hz, single phase supply
• Refrigeration Type: Self-Contained
• Max Ambient Temp (°C): 40°C
• Temperature Range: -21°C to -18°C (adjustable with SKOPE-connect -26°C to -12°C)
• Refrigerant: R290/112 × 2
• Defrost Type: Automatic
• Climate Class: 4 (Tropical)
• Cooling Type: Fan-assisted
• Noise (dB): 67​ (adjustable to 65 with SKOPE-connect Hush Mode)​
• Interior Lighting: 3 × 20 W, 1400 mm LED strip side light
• Control Type: SCS Connect (SKOPE-connect compatible)
• Connectivity: Bluetooth® wireless technology
• GEMS Class: 3L1
• GEMS Energy Consumption: 31.35
• GEMS Annual Running Cost: $3,433 p.a. (@ $0.30/kWh)
• Warranty (months): 5 Year
• Country of Origin: China
• Energy Consumption (kWh/24h): GEMS Certified
