The supplier increases the ice-bin size but leaves the original top kit on the quotation. The production head has not changed. The connection between the head and the new bin has.
Buy a documented head, bin and interface combination, not three independently attractive specifications. Keep the exact top kit and bin-control arrangement attached to the selected versions. The worked quote below catches a physical interface mismatch and replaces the missing parts of the package before the buyer compares the revised offer.
A bigger bin changes the assembly question
A modular production head makes ice; its separate bin provides the proposed storage arrangement. The interface between them includes the supported mounting/top arrangement, the ice discharge path and the applicable bin-level-control arrangement. Obtain the supplier's complete supported assembly definition, including any required accessories.
Hoshizaki Australia's IM-240ANE-28 page explicitly says the bin pictured with the machine is sold separately. It also lists bin and top-kit choices. A photograph of a complete-looking stack is therefore not the quotation's supplied-parts list.
The manufacturer's 4DM top-kit page gives a specific example: it describes that kit for two IM-240ANE heads on a B801 bin. That named arrangement is not a rule that any head fits any bin, or confirmation for an unlisted suffix/version. Use the exact supplier-supported combination for the equipment being offered.
This guide compares the assembly and supply interface. Use the commercial ice-machine guide for the wider ice-form and peak-demand brief, and the reserve-and-replenishment comparison for the separate stock question. A correctly matched top kit establishes neither production nor usable opening stock.
Put the original combination in one record
The equipment codes, drawings and provider findings below are fictional. They describe no Hoshizaki model or tested installation. The buyer has already requested an actual demand and site assessment; this example follows one subsequent quotation change.
The initial assembly proposal uses production head H1, storage bin B1, top/interface kit K1 and the head's documented bin-control arrangement BC1. The supplier's original drawing R1 addresses that combination. The buyer then requests consideration of a different bin B2. That request does not itself establish that B2 provides the desired usable reserve.
| Assembly item | Original R1 proposal | Revised quote received | Question raised |
|---|---|---|---|
| Production head | H1, exact version identified | H1 retained | Does its discharge and control arrangement work with the new complete assembly? |
| Storage bin | B1 | B2 substituted | What supported mounting/interface and control parts does B2 require? |
| Top/interface kit | K1 for H1/B1 | K1 carried forward unchanged | Does K1 actually address H1/B2? |
| Bin-control arrangement | BC1 documented with B1 | No revised B2 arrangement identified | Which applicable control mounting/interface is supplied and verified? |
Scroll the table sideways to see every column.
At this point the new pairing is unverified. The buyer asks for the actual H1/B2 assembly response before treating the amended quotation as complete. A larger bin description and an unchanged head code do not answer the interface questions.
Record the physical mismatch that returns the quote
In the fictional provider's completed drawing review, K1's discharge opening and support interface are defined for B1. On the proposed B2 top arrangement, that opening does not align with the required ice-entry opening. The BC1 control mounting shown for B1 also has no supported position on the B2 arrangement supplied in the quote.
The provider explicitly rejects K1/BC1 for this H1/B2 proposal. This is no longer simply a missing answer: the returned combination has a recorded interface conflict. The buyer keeps the useful H1 information and returns the incomplete bin revision.
| Interface | Finding on the carried-forward parts | Revision in drawing R2 | Evidence retained |
|---|---|---|---|
| Head discharge to bin entry | K1 opening does not align with the B2 ice-entry opening in the proposed arrangement | Replace K1 with the complete K2 top/interface kit documented for H1/B2 | Provider's exact assembly drawing and written support for the versions offered |
| Bin-level-control interface | BC1's B1 mounting arrangement has no supported position on the quoted B2 assembly | Specify the applicable BC2 mounting/interface parts for H1's control with B2 | Applicable control arrangement and provider commissioning scope |
| Supplied combination | Quote says H1/B2 but still lists K1 and omits the revised control parts | Issue one H1/B2/K2/BC2 package referencing R2 | Revised parts list, inclusions and outstanding site questions together |
Scroll the table sideways to see every column.
Reject the carried-forward K1/BC1 combination; request the complete R2 package. The fixing change is the matched top/interface kit and the specified control arrangement for the new bin. Buying B2 alone leaves both identified questions unresolved.
The supplier's fictional R2 response supports that exact assembly. The buyer can now retain a concrete package for the remaining purchase checks. This does not mean an adapter can make every pair compatible, nor does it provide an installation or control-adjustment procedure. Qualified providers must establish the applicable assembly and complete their required work.
Make the revised supply list match the revised drawing
Check every part of R2 against what the revised price actually includes. “Compatible kit available” leaves the order incomplete if nobody has supplied it. Equally, a control accessory shown on a drawing is not necessarily included in the head carton.
| Required R2 item | Revised quote description | Buyer check |
|---|---|---|
| H1 production head | Exact offered version, quantity one | Same version covered by R2 support |
| B2 storage bin | Exact offered bin, quantity one | No silent return to B1 or another similarly named bin |
| K2 top/interface kit | Complete supported kit, quantity one | K1 removed; required K2 parts included |
| BC2 arrangement | Applicable mounting/interface parts and commissioning responsibility explicitly included | Provider confirms what is supplied separately and what belongs to H1 |
| Assembly record | R2 and applicable documents referenced | Complete package remains linked to the supported drawing |
Scroll the table sideways to see every column.
These are supply identities, not a production calculation. The example contains one head and one bin. It neither combines two heads nor copies the actual 4DM example into the fictional package.
An alternative supported head/bin combination could also enter the comparison. The buyer progresses R2 because it directly addresses the requested B2 revision with identified parts and support. The actual storage objective, site suitability and commercial terms still need evidence before ordering.
Reopen the site and control scope after the bin changes
Ask the supplier for the complete assembled envelope, including the selected support, interfaces and any protrusions. Give the relevant providers the actual installation position, collection access, services, drains and care requirements. Separate component dimensions are not a finished installation drawing.
Keep bin-control verification in the qualified provider's commissioning scope. The buyer needs to know which arrangement is applicable, who supplies its required parts and who establishes correct operation. This guide provides no sensor-position, wiring, control-setting or bin-fill instructions.
Obtain the current instructions for the exact Australian versions. Do not inherit applicability from a similar model code, an older assembly record or an image. If a head, bin, kit or control arrangement changes again, reopen the affected support and site responses.
Use the ice-machine site survey to collect the remaining observations and provider questions. Keep production conditions, usable reserve and collection requirements attached as separate evidence rather than treating the interface correction as approval of the whole system.
Send the complete combination with the revised enquiry
Our illustrative bin change from B1 to B2 retained H1 but invalidated the carried-forward K1 discharge interface and BC1 mounting arrangement. Please quote the complete supported H1/B2/K2/BC2 combination against drawing R2, identifying the exact versions and which parts are supplied separately.
For our real system, provide written pairing support, the applicable assembly and control documents, full installed envelope and commissioning responsibilities. Keep the site, demand and usable-stock assessments visible. A picture of the head sitting on a bin does not define the supply package.
Replace the fictional identities with the exact proposed equipment and discuss the complete modular ice package with Atlantic Equipment. Compare the assembly you can actually obtain and have assessed, rather than an attractive head price beside an unrelated bin.
